LIYU Inkjet Printer (Innova PS series )

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Plate Type	Other, Roll to Roll digital printing.
Place of Origin	Anhui, China	Brand Name	LIYU
Model Number	Innova PS3204/3208-S512	Usage	Other, Baner Printing, Vinyl Printing, etc...
Automatic Grade	Automatic	Gross Power	220V 20A
Dimensions(LWH)	5200mm1000mm1600mm

Product Description

Specifications

Innova PS Inkjet Printer adopted Spectra' latest printhead POLARIS 512(15pl), 3pass resolution, speed up to 600X600dpi, 160m2/h

LIYU Innova PS Inkjet Printer

Technical Specifications

Model		PS Series Solvent Inkjet Printer
Printhead model		Polaris512/15pl/35pl
Printing resolution		600dpi/ 400 dpi 600 dpi/ 800 dpi Max.600*1600dpi
Media thickness		Max. 2mm
Media operation		Roll to roll and soft media
Max media width		Max.3,300mm
Max printing width		Max.3,200mm
Model		PS3202(35PL)	PS3204(15PL)	PS3208(15PL)
Number of printheads		2	4	8
Printing speed	3pass	78 sqm/h	85 sqm/h	160 sqm/h
	4pass	62 sqm/h	65 sqm/h	120 sqm/h
	8pass	31 sqm/h	35 sqm/h	65 sqm/h
Ink	Colors	4	4	4
	Type	solvent base ink
	Ink drying system	Preheating, postheating, drying fan and additional drying tools (optional)
	Ink supply system	Automatic ink supply system
Media	Type	Soft media, including PE, PP, ABS, PS, PU, mesh fabrics and PVC
	Roll-to-roll feeding system	Automatic feeding system
Printhead maintenance system		Automatic flash jet
Printing flow		Operate directly through RIP software
Interface		USB 2.0
RIP software		ColorPRINT/UltraPrint (optional)/Photoprint (optional)
Operating System		Windows XP
Recommended PC configuration	CPU	Core™ 2 CPU @ 2.0GHZ or higher
	Memory	2 GB or higher
	Hard drive	Min. 160 GB
Power consumption		220V 25A
Working environment	Humidity	45-75% RH
	Temperature	Ideal temperature 20-30°C (68-86°F)
Gross weight	kg	450 KG
Note: Specifications are subject to change without prior notice, all rights reserved.

Highlight Features:

1. LIYU Innova PS Printer adopted the Spectras latest printhead POLARIS, the head set high resolution and fast speed all in one, 15pl, 3PASS printing resolution & Speed reaches up to 600X600dpi & 160sqm/h, whereas the other type of heads can not match, fire frequency up to 40KHZ, with which the head firing speed ranks top one in the world. Spectra company claims the head to be known as the "Robust" in the printing industry, enjoys a long service life, based on the above characteristics, Liyu PS Printer is your best choice for a successful career.

2. Branded high-precision linear guide, Panasonic servo motor enables higher carriage speed and lower noise.

3. The printing platform enjoys one big Globoidal heating system, faster integration of ink and media to enhance the durability of the printing photos;

4. Encoder stepper system, step moves more accurate and stable.

5. Printhead ink entrance mouth enjoys a 10um imported original filter, which prevents the heads from pollution.

6. Independent research and development of dual optical fiber systems ensures print data transmission more efficient and stable.
