LIYU Spectrum KS series UV Printer

Specifications

Technical Specifications for Spectrum KS UV Printer

Specifications are subject to change without prior notice.

1. Printhead Characteristics:

Adopt the advanced US Spectra Galaxy 256 robust head, lifetime up to 5 years, fire frequency up to 20KHZ, highly improved the printing efficiency.

2. Type of Media:

Glass, ceramic, aluminum, wood, doors, cardboard, Chevron board, ceiling, MDF, metal lacquer panels, toilet cover, acrylic, plexiglass; table loading capacity of 100KG/sqm.

3. Media Detection:

Auto detection of Media size,auto. detection of Origin, auto. sensing of media thickness, auto. X/Y/Z location, available with different size and thickness of media.

4.UV curing system:

Imported UV lamp from UK, long lifetime, fitted with shutters which provide accurate curing for optimal ink adhesion to substrate, double protection to both the head and media.

5.Professional software control, high output:

 Non-stop feeding during the scanning of the carriage speed, up and down, no waste of time.

Multi pieces copy function, X/Y direction distance adjustable which enables convenient batch production;

Software automatically calculates the workload, your job is under control.

6.Vivid Colors:

K C M Y / K C M Y + W

K C M Y Lc Lm / K C M Y Lc Lm + W;

With KS2512, you can achieve bottom layer, Top covering, pure color printing can be achieved with the White color.

7.Human Security:

The design of KS2514 based on human security: Safety inspection of carriage Trajectory, increased electrical cabinet dodr switch.

8.Applications

Ad. And Sign industry

Displays and Demo industry;

Decoration  and glass industry

Leather, textile, & offset printing industry, etc.
