LIYU Victor KJ series UV Flatbed Printer

Specifications

LIYU Victor KJ series UV Flatbed Printer:

Specifications are subject to change without prior notice.

1. Printhead Characteristics:

Adopt the advanced Japanese Konica UV specialized head, 512 nozzels double staggered, built-in temperature control system, real printing resolution up to 1440dpi.

2. Type of Media:

Glass, ceramic, aluminum, wood, doors, cardboard, Chevron board, ceiling, MDF, metal lacquer panels, toilet cover, acrylic, plexiglass, etc.

3. Mechanic Superiority:

Dual lead screw & dual guider broadside scanning mechanical structure, industry-leading machinery precision; Table loading capacity of 100kg/sqm, automatic take-off and landing crossbeam, maximum media thickness up to 100mm; Sub-vacuum absorption table enables the printing on different sizes of media; Auto. detection of media, Auto. detection of Origin, pneumatic medium jack-up system plus rolling bearings enables even a single person can load the large-format media easily.

4. Electronic contol Superiority:

Independent developed entire control system,classic combination of USB and Optical fiber, LIYU patent software control system, have experienced numerous customers trials, stability is our permanent commitment.

5. Pressure & Ink supply control:

Closed-loop automatic control, reliable printing quality; pneumatic control components imported from Japan, guaranteed quality; LIYU patent Valve cleaning system, easy to maintain.

6. Color options:

the machine can be configured as K C M Y / K C M Y Lc Lm / K C M Y * 2 and K C M Y + W;  Moreover,the machine could spray with white color as bed or cover or spot-color printing.

7. Applications:

Ad. and Sign industry;

Displays and Demo industry;

Decoration and glass industry

Leather, textile and offset printing industry, etc.
