C Clamp repair vulcanizer ( Belt Repair Press ) Rubber Vulcanizing Press)

Specifications

C Clamp repair vulcanizer ( Belt Repair Press ) Rubber Vulcanizing Press)

C Clamp repair vulcanizer ( Belt Repair Press ) Rubber Vulcanizing Press)

CGXBJ-1 C Clamp repair vulcanizer ( Belt Repair Press ) Rubber Vulcanizing Press)

Product name: Electrical Conveyor Belt Repair Vulcanizer

(1) CBXBJ (Low Voltage) Technical Specification

1. Pressure: 0.8 Mpa;

2. Temperature: 145 Celsius degree ;

3. Rated Power: 2 KW;

4. Repairing maximum belt width: 2,200 mm;

5. Heating plate size: 350 mm*350mm;

6. Max. repair size: 250*250 mm.

We can make non-standard repair vulcanizer.

(2) CGXBJ (high voltage) Technical Specification:

Product name: Electrical Conveyor Belt Repair Vulcanizer

Model: CGXBJ-1

Types of repairing transport belt: Canvas, nylon, Belt with wire rope for transporting

Repair transport belt width (mm): 650—2200

The maximum cut size of repairing belt (mm):250×250

Electric heating-Dimension (mm):350×350

Vulcanizing temperature as Repairing at 145 Celsius degree : Adjustable 0-200 Celsius degree

Total power (Kw): 1.91

Temperature difference of working Electrical plate surface (Celsius degree ): ±3

Time of heating from normal temperature to curing temperature (mins): 30
