Home > Products > Tunnel UV Machine > Portable uv Curing Machine TM-UV-100
Portable uv Curing Machine TM-UV-100
- Shenzhen China
- T/T Credit Card PayPal
You May Like
-
TM-UV8m Ice Flower Effect UV Drying Conveyor Tunnel Dryer
-
TM-UV750 Screen Printing UV Dryer Machine for UV Curing
-
TM-UV-100 3KW Portable Handheld UV Curing UV Test Machine
-
TM-UV1000 2850*1300*1600 16.5KW Screen Printing UV Adhesives Drying Dryer Machine
-
TM-UV-100L 3KW Handheld UV Repair UV Curing UV Test Machine
-
TM-UV-D5 Offset uv Cure Machine
Product Details
| Condition | New | Type | Other, printing curing machine | |
| Automatic Grade | Semi-Automatic | Place of Origin | Guangdong, China | |
| Brand Name | Tamprinter | Model Number | TM-UV-100 | |
| Voltage | 220V | Power(W) | 3KW | |
| Dimension(L*W*H) | 420mmX410mmX610mm | Weight | 25kg | |
| Certification | CE Certificate | Warranty | 1 Year | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
TM-UV-100 3KW Portable Handheld UV Curing UV Test Machine
| Technical Parameters | TM-UV-100 | TM-UV-100L | |
1 | Power supply | 220V | 220V |
2 | UV lamp power | 3000W | 3000W |
3 | Main wave length | 365nm | 365nm |
4 | UV radiation length | 140mmX400mm | 140mmX600mm |
5 | UV lamp lifetime | 800 hour | 800 hour |
6 | UV case size | 420mmX410mmX610mm | 420mmX410mmX810mm |
7 | Best Radiation distance | 75-150mm | 75-150mm |
8 | Total Net weight | 25KG | 35KG |
3kw Mercury Lamp Dry Pegmentalne Red Colors Need About 8 Sec,black Ink Longest,
transparent UV Varnish Shortest, also Can Use Gallium Lamp
Product name:Portable UV Curing Machine
Item: TM-UV-100-3kw
Details:
Portable UV curing machine for UV glue, UV ink, UV test.
Application for UV repair, wood floor UV curing, Wall corner UV curing which the big UV machine can not cure.
Features:
Small size with light weight,
Portable design, one lamp, easy operation.
One side and multi-side curing flexible controlling.
Special for test(UV ink, UV oil, UV painting, UV coating )
Economic style with steady performance.
TM-LED1020 Portable Mini LED MDF Plate UV Machine

1. Advantage of UV LED:
n High efficient and low temperature, prevent material to deformation or turn to yellow;
n Convenient to install on any of the existing drying equipment;
n Ultra low energy consumption, electricity saving 80%~90%;
n Long using life, curing once turn it on,need’t to wait, stable light source;
n Effective curing the common UV ink, do not need to replace Special ink, the same efficiency;
n Green environmental protection, low noise, no ozone, no mercury pollution, no heat radiation;
n with 2 years warranty
2. Comparison of LED UV and traditional UV light source:
Item | LED UV light source (1m width,3 groups LED UV light,480W/group) | Traditional light source (1m width,2 set UV lamps, 5.6KW/lamp) |
Using life | Over 20000 hours | Around 800 hours |
machine power | 1.6KW | 14KW |
Electric cost | Around 832 USD per year | Over 7280 USD per year |
Based on 3120hours/year,electric price 0.167USD/Kw. | Based on 3120hours/year,electric price 0.167USD/Kw. | |
Maintenance costs | 0 USD/year | 700 USD/year |
Within using life | Change UV lamps 4 times per year | |
Cost saving | At least save 7148 USD/year | |
Technical parameters
0.95*1.5*0.95m,belt wide 800mm
Light is an array of integrated version ,130*130MM LED lamp block,Arranged according to the customer's width AND speed
12 block*USD2000+body=USD25800
Application:
It is apply to the special effects such as wrinkle, frosted refraction gem crystal and convex oil on the bullion paperboard, metal, glass, plastic, and also the UV curing of the offset printing ink on the offset press production.
Features:
1. With Teflon or stainless steel net, transmit speed steady and can be adjusted.
2. With two UV lighting tubes, can turn on the light according to the need.
3. Wink-dry make the surface of the stocks high hardness and rub resistance.
4. Tunneling-based make the whole machine light barrier good and without harm.
5. Equipped with powerful nether induced draughe system and big intake airway, can absorbs the stock on the mesh belthard. It can be used with production line and other equipment easily.
UV drying machine for screen printing
UV drying machine for offset printing
Portable UV curing machine
Portable LED UV curing machine
LED UV curing machine
