Home > Products > Common open type > Automatic Transfer Switch for Generator Set 1200kw
Automatic Transfer Switch for Generator Set 1200kw
- Qingdao
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Shanhua | |
| Model Number | HL1200GF | Output Type | AC Three Phase | |
| Speed | 1500RPM | Frequency | 50Hz | |
| Rated Power | 1200kW/1500kVA | Rated Voltage | 380/220V 400/230V | |
| Rated Current | 2160A |
Product Description
Specifications
- automatic transfer switch for generator set 1200kw- Cummins OEM
- 100% copper wire
- Factory supply
automatic transfer switch for generator set 1200kW
Specification of genset
Genset model:HL1200GF
Prime power: 1200KW/1500KVA
Standby power: 1320KW/1650KVA
Power factor: 0.8
Rated Voltage: 400/230V
Rated frequency (HZ): 50
Dimensions (mm) (L×W×H): 5900×2200×2900
Weight (kg): 11000
Specification of diesel engine
Engine Model: KTA50-GS8
Manufacturer: Commins
Governor: E
Air intake way: Turbo-charged
Cylinders/Arrangement: 16/V
Bore× Stroke(MM): 159×159
Fuel Consumption Rate(L/h): 309
Lubricating oil capacity(L): 204
Coolant capacity (L): 380
Compression ratio: 13.9:1
Displacement, total (L): 50.3
Net weight (kg): NA
Engine speed (rpm): 1500
Max Power (kW): 1429
Starting Method: DC24V electrical starting
Specification of alternator
Alternator model: HLF1200
Connecting Type: 3 Phase and 4 Wires
Number of Bearing: 1
Protection Grade: IP21
Altitude: ≤1000m
Exciter Type: Brushless, Self-exciting, AVR automatic voltage regulating,100% Copper winding wire
Insulation Class: H
Telephone Influence Factor (TIF): ≤50
Voltage Regulation, Steady State: ≤±1%
Transient State Voltage: ≤-15%~+20%
