VPE Series Off-Line UPS
Negotiable
/ Unit
500 Units(Min.Order)
- 0 per Month
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SAKO | |
| Model Number | VPE-500VA-1500VA | Phase | Single Phase | |
| Protection | Short Circuit | Weight | 5-12 | |
| Output Voltage | 110/120 VAC or 220/230/240VAC ±10% | Application | Security / Monitoring / Alarm |
Product Description
Specifications
1.Overload/Short Protection2.High/Low Voltage Protection
3.Wide Input Voltage Range Option
4.Colored LED display
| Line interactive UPS (PWM output)-Plastic case | ||||||||
| Model # | VPE-500 | VPE-600 | VPE-800 | VPE-1000 | VPE-1200 | VPE-1500 | ||
| Capacity | 500VA/300W | 600VA/360W | 800VA/480W | 1000VA/600W | 1200VA/720W | 1500VA/900W | ||
| AVR | No | 3 steps of AVR, CPU controlled | ||||||
| INPUT | ||||||||
| Input voltage range | 110V: 90~132±5Vac | 110V: 85~150Vac±5Vac | ||||||
| 220V:175~265±5Vac | 220V:145~290Vac±5Vac | |||||||
| Input frequency range | 50Hz / 60Hz (Auto sensing) | |||||||
| OUTPUT | ||||||||
| Output voltage range | 110V: 90~132±5Vac | 110V: 102~132Vac | ||||||
| 220V: 175~265±5Vac | 220V:200~255Vac | |||||||
| Output frequency (DC mode) | 50±0.5Hz / 60±0.5Hz | |||||||
| Wave form | PWM (DC Mode) | |||||||
| Transfer time | Typical 2~6ms, Max.10ms. | |||||||
| BATTERY | ||||||||
| QTY & capacity of battery | 1 pc*12V4.5Ah | 1 pc*12V7Ah | 1 pc*12V9Ah | 2 pcs*12V7Ah | 2 pcs*12V7Ah | 2 pcs*12V9Ah | ||
| Charging period | 4~6 hours recover to 90% capacity | |||||||
| PROTECTION & FUNCTION | ||||||||
| PROTECTION | 1. Battery low voltage protection 2. Overload protection 3. Short circuit protection | |||||||
| FUNCTION | 1. Auto re-starts when AC recovers 2. Silence setup 3. Automatic charging (offline charging) | |||||||
| MANAGEMENT | ||||||||
| RJ45/11 & USB | Optional | |||||||
| PHYSICAL | ||||||||
| Unit dimension (mm) | 314*97*143 | 345*146*162 | ||||||
| Color box dimension (mm) | 370*145*230 | 435*223*242 | ||||||
| Master box dimension (mm) | 380*312*485 | 466*450*264 | ||||||
| Pcs in one master carton | 4 | 2 | ||||||
| Gross weight (1pc, kg) | 4.2 | 4.9 | 6.2 | 11.2 | 13.0 | 15.0 | ||
| Net weight (1pc, kg) | 4.0 | 4.6 | 5.8 | 11.0 | 12.8 | 14.8 | ||
| Loading capacity (20' ctrn) | 2160 pcs | 960 pcs | ||||||
| Loading capacity (40' GP) | 4440 pcs | 1920 pcs | ||||||
