PC Power Supply
US$ 18 - 90
/ Piece
500 Pieces(Min. Order)
- Shenzhen Shanghai Hongkong Ningbo
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SAKO | |
| Model Number | 500-2000VA | Phase | Single Phase | |
| Protection | Other, Short Circuit, High/Low Voltage Protection | Weight | 7KG-15KG | |
| Output Voltage | 220V/110V | Type | Standby | |
| Application | Other, Computer, Compatibility With Generators |
Product Description
Specifications
1.with AVR function2.Intelligent Battery Management
3.Smart RS232 & RJ11 Option
4.Wide Input Voltage Range Option
| SAKO PCX Series TECHNICAL PARAMETER | ||||||
| Product | Requirements | Model 1 | Model 2 | Model 3 | Model 4 | Model 5 |
| Power (VA) | PCX-500 | PCX-650 | PCX-800 | PCX-1000 | PCX-1500 | |
| Input | Voltage (VAC) | 110VAC ± 25% | ||||
| Frequency (Hz) | 50/60Hz ± 10% | |||||
| Output | Voltage (Inverter Mode) | 110VAC ± 10% | ||||
| Capacity (W) | 500VA/300W | 650VA/360W | 800VA/480W | 1000VA/600W | 1500VA/880W | |
| Frequency (Inverter Mode) | 50/60Hz ± 10% | |||||
| Transfer Time (ms) | ≤6ms Typical | |||||
| Waveform | Modified-Sinewave | |||||
| Protection | Spike & Surge Suppression | Yes | ||||
| Over/Under Voltage | Switch To Bat. O/P When Mains Over Regulation Range | |||||
| Over Load /Short Circuit | Fuse & Current Limited For Both Mains And Battery Modes | |||||
| Function | Cool Start | Cool Start Computer Even There Is No Main Power | ||||
| Automatic Recharge | Automatic Charge When UPS Is Off | |||||
| Battery | Type | Lead-Acid Miantenance-Free | ||||
| DC Bus | 12V7.0Ah | 12V9.0Ah | 12V7.0Ah | 12V9.0Ah | ||
| Number | 1 PC | 2 PCS | ||||
| Recharge Time | 8 Hours ≥ 90% | |||||
| Back Up Time(One PC) | 8-15mins | 10-18mins | 15-25mins | 20-30mins | 25-45mins | |
| Physical | Weight (KGs) | 5 | 5.5 | 6.5 | 10.5 | 11.5 |
| Shipping Wt. (KGs) | 5.6 | 6 | 7 | 11 | 12 | |
| Product Dimensions (mm) | 335*95*160 mm | 355*120*195 mm | ||||
| Packing Dimensions (mm) | 375*170*200 mm | 420*190*250 mm | ||||
| Software | Windows & NT | Auto Save & Shut Down | ||||
| Efficiency | AC-AC | 1 | ||||
| DC-AC | 0.6 | |||||
| Acoustic | Noise Level (dB) | ≤ 45 dB | ||||
| Environmental | Temperature | -5°C ~ 45°C Degree | ||||
| Humidity | 20% to 90% | |||||
| Power Outlets | No. And Types | 2 SOCKETS | 3 SOCKETS | |||
