Home > Products > Powered by Doosan Engine > Hot Sales100kw Doosan Daewoo Diesel Power Genset Price With CE Certificate
Hot Sales100kw Doosan Daewoo Diesel Power Genset Price With CE Certificate
- Shanghai Port
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
50KW Water Cooling Diesel Genset Powered by DOOSAN Daewoo
-
Global Warranty 600KW Daewoo Diesel Generator Set
-
640kVa Industrial Diesel Generators Powered by Doosan Engine With CE and ISO Certificates
-
Open Type 550KW 50HZ Powered by Daewoo Engine Generator Sets
-
12.5kva Daewoo Diesel Generator Set With Water Cooling
-
500KW Water Cooling Diesel Genset Powered by DOOSAN P222LE-S
Product Details
| Place of Origin | Jiangsu, China | Brand Name | kangdong | |
| Model Number | KD-100GF | Output Type | AC Three Phase | |
| Speed | 1500RPM | Frequency | 50Hz | |
| Rated Power | 500kW | Rated Voltage | 400/230V | |
| Rated Current | 900A |
Product Description
100kw doosan daewoo diesel power genset price with CE certificate
| 1. Specification of genset | ||||||||
| Gensets model | KD-100GF | |||||||
| Prime power(KW) | 100 | |||||||
| Rated voltage(V) | 400 / 230 | |||||||
| Rated current(A) | 902 | |||||||
| Rated frequency(HZ) | 50 | |||||||
| Rated Speed (rpm) | 1500 | |||||||
| Power Factor | 0.8(lagging) | |||||||
| Dimensions(mm) (L×W×H) | 3600x1420x1700 | |||||||
| Net Weight(kg) | 4200 | |||||||
| 2. Specification of diesel engine | ||||||||
| Engine brand | Doosan Daewoo | |||||||
| Engine model | P086PI-1 | |||||||
| Air Intake System | Turbocharged, Air/Air Cooling | |||||||
| Fuel System | BOSCH P type fuel pump | |||||||
| Cycle | Four stroke | |||||||
| Cylinder Arrangement | 6 in ”L | |||||||
| Displacement | 21.927L | |||||||
| Bore×Stroke (mm×mm) | 128 x 142 | |||||||
| Compression Ratio | 14.6:1 | |||||||
| Rated RPM | 1500rpm | |||||||
| Cooling System | Forced Water Cooling Cycle | |||||||
| Max. Standby Power at Rated RPM | 603KW | |||||||
| Governor Type | Electronic | |||||||
| Starting Method | DC24V electrical starting | |||||||
| Exhaust System | ||||||||
| Exhaust Gas Flow | 93.9m3/min | |||||||
| Exhaust Temperature | 598°C | |||||||
| Max Back Pressure | 6kPa | |||||||
| Air Intake System | ||||||||
| Max Intake Restriction | 6.35kPa | |||||||
| Consumption | 31.8m3/min | |||||||
| Air Flow | 1286m3/min | |||||||
| Fuel System | ||||||||
| 100%(Standby Power) Load | 130.0 L/h | |||||||
| 75%( Standby Power) Load | 99.8 L/h | |||||||
| 50%( Standby Power) Load | 68.3 L/h | |||||||
| Oil System | ||||||||
| Total Oil Capacity | 40L | |||||||
| Oil Consumption | ≤4g/kwh | |||||||
| Engine Oil Tank Capacity | 33L | |||||||
| Oil Pressure at Rated RPM | 345-483kPa | |||||||
| Cooling System | ||||||||
| Total Coolant Capacity | 113L | |||||||
| Thermostat | 71-85°C | |||||||
| Max Water Temperature | 103°C | |||||||
| 3. Specification of alternator | ||||||||
| Alternator brand | Stamford | |||||||
| Alternator model | HCI544F-S | |||||||
| Excitation | Brushless ,Self-exciting, AVR automatic voltage regulating,100% Copper winding wire | |||||||
| Number of Phase | 3 | |||||||
| Connecting Type | 3 Phase and 4 Wires | |||||||
| Number of Bearing | 1 | |||||||
| Power Factor | 0.8 | |||||||
| Protection Grade | IP23 | |||||||
| Altitude | ≤1000m | |||||||
| Insulation Class, Temperature Rise | H | |||||||
| Telephone Influence Factor (TIF) | ≤50 | |||||||
| THF | ≤2% | |||||||
| Voltage Regulation, Steady State | ≤±1% | |||||||
| Transient State Voltage | ≤-15%~+20% | |||||||
| 4. Specification of control Panel(with GU620A controller) | ||||||||
| The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function. | ||||||||
| The features of GU620A controller: | ||||||||
| GU620A is a new generation Automatic control module for single Genset, which adopts bran-new outline configuration, focus on the requirements of customers, and perfectly improves the performance of controller. It fully meets the auto control requirements of different kinds of Genset for user or special assembly factory. | ||||||||
| The module also monitors and protects the engine, indicating operational status, fault conditions and metering on the front panel LCD and LED’s. | ||||||||
]
1.Q:What's the power range of your generator sets?
A:The main products are ranging from 5KW to 2500KW.
2.Q:How many types of the generator sets do you have?
A:Diesel,gasoline,natural gas,marine,water pump,high-voltage generator sets,etc.
3.Q:Where is your factory located?
A: Our factory is in Taizhou city, Jiangsu Province, China.
It's near Shanghai & Ningbo port.
4.Q:What is the material of your products?
A: Iron,Steel,plastic,etc.
5.Q:How about quality control in your factory?
A:"Quality is the life".
We are always paying great attentions to
quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
FAQ:
1.Q:What's the power range of your generator sets?
A:The main products are ranging from 5KW to 2500KW.
2.Q:How many types of the generator sets do you have?
A:Diesel,gasoline,natural gas,marine,water pump,high-voltage generator sets,etc.
3.Q:Where is your factory located?
A: Our factory is in Taizhou city, Jiangsu Province, China.
It's near Shanghai & Ningbo port.
4.Q:What is the material of your products?
A: Iron,Steel,plastic,etc.
5.Q:How about quality control in your factory?
A:"Quality is the life".
We are always paying great attentions to
quality controlling from the beginning to the end. Every piece of goods is tested strictly one by one before packing.
We keep goods to meet the standard of CE,CCC, ISO9001:2000.
