G.652D 27years experience for 48 core outdoor armour fiber optic cable manufacture Quality Choice

FOB Price

US$ 0.1 - 9 / Meter

1000 Meters(Min. Order)

Port qingdao port
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	hongan
Model Number	GYTY53--(2-216)

Product Description

Specifications

1.27 years experience
2. ISO9001,ISO14001
3.IEC60794,IEC60793
4.Mini. Order: 1000meters
5.FOB price:$0.1-9/meter

Characteristics of product:
rrugated steel tape as armour,loose tube stranding and double sheaths;
2.loose tube material has good hydrolysis resistance performance and high strength;
pact structure, excellent water-blocking performance;
4.strict manufactureing processes.good mechanical performance and environmental properties.

Applications:
buried, aerial;
relay communication system;
core network, metropolitan area network and access network etc.

Temperature:
operating temperature:-40°C~+70°C

Standards:
IEC811,IEC60794,IEC60793

Optional:
1.the structure diameter can be designed for customers;
2.to design flame resistance, anti-rodent, anti-ant cable according to the customers' demands.

Cable structure:

Structural parameters:

fiber count	nominal diameter (mm)	nominal weight (kg/km)	permitted tensile LT/ST(N)	permitted crush LC/SC (N)	bend radius static state/dynamic state (mm)
2-36	12.8	187	600/1500(1000/3000)	300/1000(1000/3000)	12.5D/25D
38-60	14	208	1000/3000	1000/3000	12.5D/25D
62-72	14.7	220	1000/3000	1000/3000	12.5D/25D
74-96	16.1	260	1000/3000	1000/3000	12.5D/25D
98-120	17.6	293	1000/3000	1000/3000	12.5D/25D
122-144	19.1	356	1000/3000	1000/3000	12.5D/25D
146-216	19.3	375	1000/3000	1000/3000	12.5D/25D

main product lines:

Main Product Lines For Fiber Optic Cable
No.	Name	Type	Manufacture	Quantity
1	Optical fiber coloring &rewingding line	LCF110	SWISSCAB(Switzerland)	1
		OFC52-660	NEXTROM(Finland)	1
		GFP-UV-H	M&S(Austria)	1
		WY-ES1800	weiye(China)	4
2	Optical fiber secondary coating line	LCE110/12	SWISSCAB(Switzerland)	1
		OFC45-655	NEXTROM(Finland)	1
		EP-12/236	Yupin(China)	4
3	Optical fiber ribbon secondary coating line	OFC45-655	NEXTROM(Finland)	1
3	Optical fiber ribbon secondary coating line	EP-18/400	Yupin(China)	4
4	Optical Fiber Ribbon Production Line	LCF 808	SWISSCAB(Switzerland)	1
			Royi(USA)	1
		KOBE STEEL 12F	KOBE(Japan)	1
		12F	weiye(China)	1
5	SZ stranding line for optical fiber loose tube	LCM106/12	SWISSCAB(Switzerland)	1
		LCM106	SWISSCAB(Switzerland)	1
		GL060-12/800	Chengdu(China)	1
		EP-6/800	Yupin(China)	4
6	Steel wire armoring strander for fiber optic cables	CH-GSL-18+30/400	Changhua(China)	1
7	Sheathing extrusion line	LCE131	SWISSCAB(Switzerland)	2
		SJ120×25	Changhua(China)	1
		D-S φ63	DAVIS(USA)	1
		φ90-1600	weiye(China)	4
		φ55-630	Dachen(China)	12

Test equipments:
