GYDTA 96 core G.652D ribbon outdoor optical fiber cable
- QINGDAO port
- T/T L/C D/P D/A T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | hongan | |
| Model Number | GYDTA-96 | Conductor Material | Other, fiber | |
| Insulation Material | Other, PBT | Jacket | PE | |
| Number of Conductors | 96 | Application | duct, aerial, duct, aerial |
Product Description
Specifications
1.27 years experience for fiber optica cable2.ISO9001,ISO14001
3.Mini. order: customer's demands
4.FOB price: 1.5-3USD/M
Characteristics of product:
1.good mechanical performance, temperature properties;
2.loose tube of PBT material las good hydrolyis resistance performance and high strength;
3.tube filing with the special imported jelly compound to protect the fibers
4.the concentration of the fibers is high,the diameter of the optical fiber cable is smaller, so the weight of the cable is lighter
5.excellent moisture resistance, water-blocking performance;
Applications:
duct,aerial;
metropolitan area network and access network etc.
Temperature:
operating temperature:-40°C~+70°C
Standards:
IEC811,IEC60794,IEC60793
Optional:
1.the structure diameter can be designed for customers;
2.to design flame resistance, anti-rodent, anti-ant cable according to the customers' demands.
3.fiber:G.652,G.655
structural parameters:
| fiber count/fiber ribbon | nominal diameter (mm) | nominal weight (kg/km) | permitted tensile LT/ST(N) | permitted crush LC/SC (N) | bend radius static state/dynamic state (mm) |
| 48-196/12 | 20.0 | 348 | 1000/3000 | 300/1000 | 10D/20D |
| 208-240/12 | 21.7 | 410 | 1000/3000 | 300/1000 | 10D/20D |
| 252-288/12 | 23.8 | 466 | 1000/3000 | 300/1000 | 10D/20D |
| 300-360/12 | 24.6 | 495 | 1000/3000 | 300/1000 | 10D/20D |
| 300-432/12 | 26.6 | 558 | 1000/3000 | 300/1000 | 10D/20D |
cable structure:
product line:
test equipments:
