China Cheaper Price Push Clamp 5 Pole Wire Connector
- Ningbo or Shanghai
- T/T Credit Card PayPal
You May Like
-
Newest Push In Wire Multi Pin Wire Connector 5P 0.75-2.5mm2
-
Cheaper 4 Wire Push Wiring Connector 0.75-2.5mm2
-
Cheaper Electrical 4 Wire Connector 0.75-2.5mm2
-
Cheaper Electrical 4 Poles 250V Wire Connector 0.75-2.5mm2
-
Hot Sell Building 4 Pin Block Terminal Connector 250V
-
Hot Sell PCT Auto Plastic Wire Connector 2P With High Quality
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chenf | |
| Model Number | PCT258105 | Type | Other, Wire Connector |
Product Description
Specifications
China Cheaper Price Push Clamp 5 Pole Wire Connector1, Push Fit Connector Cage Clamp
2, 250V 24A 5 Wire
3, CE,Rohs
China Cheaper Price Push Clamp 5 Pole Wire Connector
-----5 Poles Wiring Connector------
-----For building construction----
----Easy to Install----
Wire Connector Terminals Block PCT Connection Wiring Connector
-Features:
Product Name : Plug-in wire connectors
Product Origin : China
Product Type : PCT258105
Product categories : PCT258 Series connector suitable for connection between a single hard wire
Package quantity : 100pieces
Number of channels : 5
Rated : 250V
Current Rating : 24A
Can be accessed by conductor cross section [mm²]: 0.75-2.5mm²
Can be accessed by conductor cross section [AWG]: AWG18-12
Color: Orange
Connection: plug wire
Wiring direction : positive
Pollution degree : 2
Can withstand instantaneous peak voltage : 4KV
Insulation material : PA
Flammability rating : UL94 V-0 or (V-2)
Stripping length : 12-13mm
Convenient: wire stripping can be inserted directly after, can be repeated use.
Reliable: each contact shrapnel independent, strong combination of different wire diameter security sub.
Practical: product design with test holes, the line testing do not need to remove the tape.
Application:
The electrical connection in the home installs all kinds of lamps and lanterns 2 terminal box conductor transformation and line connection
3 kitchen appliances and all kinds of electrical connection in the 4 small power fixed appliances such as fan connection
Steps:
1 wire stripping preparation: according to the length of product labeling strip wire sheath
2 wires: will strip the skin of wire plug the connector hole completely
3 wires remove: single strand conductor turned around, and at the same time to work, removable wires.
4 connection test: products have test hole, convenient line detection.
- Chenf Electric Group Limited. (called "Chenf" for short) is a wholly owned subsidiary of Chenf Electrical Group Limited. Founded in 2008, we are a modern enterprise specialized in offering one-stop service to customers.
- Chenf concentrates on the design, production and sales of renewable energy product, hi-voltage product, low-voltage product, pneumatic actuator, etc
- Chenf will continue to take "create value for customers.
Enterprise Vision: To create electrical products airline carrier.
Wire Connector Terminals Block PCT Connection Wiring Connector
-Payment and Shipping:
Wire Connector Terminals Block PCT Connection Wiring Connector
Q1: Are you a manufacturer?
A1:yes. We have 8 years export exprience.
Q2: Delivery time?
A2:Will send the goods out within 48 hours after the order confirmed.
Q3: After Sales Service?
A3: if u have any questions about the received product, we will try our best to solve it.
Q4: Return the goods?
A4: If the product really has quality problem, we will accept return the old one and send again.
Whising you a great Shopping Time!
Wire Connector Terminals Block PCT Connection Wiring Connector
