Product Details
| Place of Origin | Zhejiang, China | Brand Name | Chenf | |
| Model Number | PCT258103 | Type | Other, Wire Connector |
Product Description
Specifications
Auto Electrical Wire Connectors For Building Lighting1, Push Fit Connector Cage Clamp
2, 250V 24A 3 Wire
3, CE, Rohs
Cheaper Price Auto Electrical Wire Connectors For Building Lighting
-----3 Poles Wiring Connector------
-----For building construction----
----Easy to Install----
Wire Connector Terminals Block PCT Connection Wiring Connector
-Features:
Product Name : Plug-in wire connectors
Product Origin : China
Product Type : PCT258103
Product categories : PCT258 Series connector suitable for connection between a single hard wire
Package quantity : 100pieces
Number of channels : 3
Rated : 250V
Current Rating : 24A
Can be accessed by conductor cross section [mm²]: 0.75-2.5mm²
Can be accessed by conductor cross section [AWG]: AWG18-12
Color: Orange
Connection: plug wire
Wiring direction : positive
Pollution degree : 2
Can withstand instantaneous peak voltage : 4KV
Insulation material : PA
Flammability rating : UL94 V-0 or (V-2)
Stripping length : 12-13mm
Convenient: wire stripping can be inserted directly after, can be repeated use.
Reliable: each contact shrapnel independent, strong combination of different wire diameter security sub.
Practical: product design with test holes, the line testing do not need to remove the tape.
Application:
The electrical connection in the home installs all kinds of lamps and lanterns 2 terminal box conductor transformation and line connection
3 kitchen appliances and all kinds of electrical connection in the 4 small power fixed appliances such as fan connection
Steps:
1 wire stripping preparation: according to the length of product labeling strip wire sheath
2 wires: will strip the skin of wire plug the connector hole completely
3 wires remove: single strand conductor turned around, and at the same time to work, removable wires.
4 connection test: products have test hole, convenient line detection.
