Home > Products > New Products > 110/220V Iron Leaf 9238 Axial AC Fan 92x92x38mm
110/220V Iron Leaf 9238 Axial AC Fan 92x92x38mm
- 2000 Piece / Pieces per Month
- SHENZHEN
- Credit Card
You May Like
Product Details
| Electric Current Type | AC | Mounting | Roof Fan | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Model Number | M088BA1H | Voltage | 220V | |
| Power | 16W | Air Volume | 46CFM | |
| Speed | 2600RPM | Certification | CE, UL, ROHS |
Product Description
Specifications
1. Voltage:110V/220V2. Bearing: Ball Bearing
3. CE/ROHS /UL/FCC
4. Customizable
110/220V Iron Leaf 9238 Axial AC Fan 92x92x38mm
Material
Framework.............................................Aluminum Alloy
Impeller................................................Plastic (UL: V-0)
Protection....................................Impedance Protected
Temperature range.........................................-20c~70c
110/220V Iron Leaf 9238 Axial AC Fan 92x92x38mm
| Size(mm) | Model | Beaing system | Rated voltage (v) | Freq(HZ) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Air Flow(CFM) | Air Flow (m3/mim) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| Iron 92*92*38mm | M088AA1H | Ball | 110/120 | 50/60 | 0.24 | 16 | 2600/3000 | 46/54 | 1.30/1.52 | 4.69/5.50 | 38/43 | 480 |
| M088AA2H | Ball | 220/240 | 50/60 | 0.12 | 16 | 2600/3000 | 46/54 | 1.30/1.52 | 4.69/5.50 | 38/43 | 480 | |
| M088AA1M | Ball | 110/120 | 50/60 | 0.22 | 14 | 2300/2700 | 42/50 | 1.19/1.41 | 4.28/5.09 | 35/40 | 480 | |
| M088AA2M | Ball | 220/240 | 50/60 | 0.10 | 14 | 2300/2700 | 42/50 | 1.19/1.41 | 4.28/5.09 | 35/40 | 480 |
,,Shipment
1. FOB Shenzhen or HongKong (mass production)
2. DHL,UPS,FEDEX,TNT or any other international express (sample or small quantity)
<<<More details can be discussed.>>>
,,Payment
T/T and Western Union
1. The payment for the high value sample will be charged.
2. The payment for the low value sample is free, but the freight should be paid by you.
,,Delivery Time
Generally, 500~1000pics 10 days after confirming the PI
,,Our Company
Alibaba: http://topfan-china.en.china.cn
Shenzhen Topfan-China Development Technology Co., Ltd, founded in 1996 in Shenzhen China, is professional manufacturer on dc brushless fans and ac fans. Products are ISO9000, UL, CE, RoHS and TUV certificated and good sellers both at home and abroad, including Europe, North America, Asia(Korea and India) etc. The products, including brushless fans, cross flow fans, blower fans, centrifugal fans, dc brushless motor, shades pole and RC ac fans etc, are being widely used in the information technology, network communications as well as industrial production equipment, medical equipment, home appliances and others.
Based on mutual benefit and development, we'll make our biggest efforts to do everything better for our customers.
