20*20*10mm High Air Flow Ventilation Fan / dc Cooling Axial Fan 5v 12v
US$ 1 - 3
/ Piece
500 Pieces(Min. Order)
- shenzhen
- T/T
You May Like
Product Details
| Electric Current Type | DC | Mounting | Other, cooling fan | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Brand Name | MX/ODM/OEM | Model Number | MX2010AB(S)H1 | |
| Voltage | 12V | Power | 0.84W | |
| Air Volume | 1.70CFM | Speed | 20000rpm | |
| Certification | Other, UL, CE, ISO9000, UL ,CE, RoHS, TUV |
Product Description
20*20*10mm high air flow ventilation fan / dc cooling axial fan 5v 12v
General Specifications:
Frame | plastic(UL94v-0) |
Impeller | plastic(UL94v-0) |
Bearing type | Sleeve Bearing and Dual Ball Bearing |
Leadwire | UL1571AWG#28 or Equivalent (+):Red(-):Black |
Motor | Impedance Protected and Reverse Polarity Protected |
Voltage | 5V,12V |
Certification | ISO9000, UL ,CE, RoHS, TUV |
Expected Life:
1.Ball Bearing 50,000 hours(40°c)
2.Sleeve Bearing 30,000 hours(40°c)
Allowable Ambient Temperature Range
1.-10°c~+70°c (Operating)
2.-40°c~+70°c (Storage)
3.(non-condensing environment)
Specification:
| Model | Bearing Type | Rated Voltage | Operating Voltage | Input Current | Input Power | Speed | Max Air Flow | Max Static Pressure | Noise | Weight | ||
| MX2010AB(S)H5 | B.S | 5 | 2.8-5.5 | 0.13 | 0.65 | 15000 | 1.25 | 0.04 | 0.14 | 35.01 | 27.00 | 5.00 |
| MX2010AB(S)M5 | B.S | 5 | 2.8-5.5 | 0.10 | 0.50 | 10000 | 0.73 | 0.02 | 0.05 | 11.77 | 22.00 | 5.00 |
| MX2010AB(S)L5 | B.S | 5 | 2.8-5.5 | 0.07 | 0.35 | 8000 | 0.42 | 0.01 | 0.04 | 8.73 | 21.00 | 5.00 |
| MX2010AB(S)H1 | B.S | 12 | 7.0-13.8 | 0.07 | 0.84 | 20000 | 1.70 | 0.05 | 0.24 | 60.90 | 30.00 | 5.00 |
| MX2010AB(S)M1 | B.S | 12 | 7.0-13.8 | 0.50 | 0.60 | 15000 | 1.25 | 0.04 | 0.14 | 35.01 | 27.00 | 5.00 |
| MX2010AB(S)L1 | B.S | 12 | 7.0-13.8 | 0.03 | 0.36 | 10000 | 0.73 | 0.02 | 0.05 | 11.77 | 22.00 | 5.00 |
