Home > Products > Actuators&Valves > SEH50... Electro-thermal Actuator
SEH50... Electro-thermal Actuator
- Ningbo/Shanghai
 - T/T Credit Card

You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Menred | |
| Model Number | SEH50 | Type | Other, Heating, Electro-thermal actuator |
Product Description
SEH50...Electro-thermal Actuator
Introduction
The actuator apply to optimum control of valves on heating circuit distributors, small valves, dynamic balanc valves and so on.
1. Wax element from France, PTC heating to start.
2. Spring re-set function, normal closed and normal open are available.
3. Noiseless.
4. Stroke position indicator.
5. Nut connects made install and dismount easy.
Application
Fitted on manifolds or small valves for the control of warm-water(floor) heating systems used in commercial buildings, residential buildings, light industrial buildings...
Technical data
Voltage: 230V/24V
Power consumption: 2W
Force: 110N
Stroke: ≥ 3mm
Closing and opening time: 3-5min
Valve interface: M30X1.5 mm
Ambient temperature:-5℃-50℃
Cable Length: 900 mm
Housing material: PC
Protective housing: IP52
Selection table
| Model number | Voltage | Stroke |
| SEH50.23 | 230V | 11mm-14mm |
| SEH50.24 | 24V | 11mm-14mm |
| SEH50.23 | 230V | 12mm-15mm |
| SEH50.24 | 24V | 12mm-15mm |
