Matrix Switcher Ptz Controller PE5125
- Shanghai Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
IP Keyboard Controller for ip Camera/ptz Controller
-
Network Cctv Keyboard Controller for NVR/DVR/Matrix
-
PE5125ST Video Ptz Controller for Cctv
-
PE5128 IP HD Camera Ptz Controller Joystick
-
PE5127 Keyboard Controller Joystick for HD-SDI Camera, SDI PTZ
-
Modular Analog 128*32 Video Matrix Switcher For Surveillance System
Product Details
| Place of Origin | Zhejiang, China | Brand Name | PEARMAIN | |
| Model Number | PE5125 |
Product Description
Keyboard ptz controller/Main keyboard for NVR/DVR

User log-in and permission
1 system administrator, 1 user administrator, 64 operation user
Operation mode including:
Matrix operation: to work with PE full series matrix switcher, including usual operation, menu programming, etc.
VCR (DVR) operation mode: to have all functions of DVR panel
Multiplexer operation mode: PE5124S can control ROBOT (or others) multiplexer
Receiver/driver, speed dome operation mode: it can control all PE receiver/driver, or PLECO D/P Samsung, protocol receiver/driver and Speed dome camera
Communication port:
4 data communication port and 1 contact closure port for Matrix, DVR, multiplexer, receiver/driver, etc.
Joystick and button self-inspection:
It can inspect and display index of joystick center position, rotation,
Macro, special for PE125 keyboard controller, PE5124ST without Macro.
Display method: 240mm×128mm LCD
Communication mode: RS-485/RS-422/RS-232/Ethernet 10/100M
Communication speed: can set
Connection method: RJ45
Relay drive: 1A/220V/110VAC or3A/24VDC
Key quantity: 47
Pan-tilt control: 3 or 4-asis joystick (3-joystick is default)
Power failure protection: 10years
Working temperature: -10℃~+45℃
Working voltage: 9VDC
Power: 5.0W
Weight: 1.5KG
Dimension: 370(L)×190(W)×55(H)mm
Installation method: desktop
Communication mode | RS-485/RS-422/RS-232/Ethernet 10/100M |
Communication speed | can set |
Connection method | RJ45 |
Relay drive | 1A/220V/110VAC or 3A/24VDC |
Key quantity | 47 |
Pan-tilt control | 3 or 4-asis joystick (3-joystick is default) |
Power failure protection | 10 years |
Working temperature | -10℃ ~ +45℃ |
Working voltage | 9VDC |
Power | 5.0W |
Weight | 1.5KG |
Dimension | 370(L)×190(W)×55(H)mm |
Installation method | desktop |
"Pearmain Electronics Co., Ltd" was founded in 1996, which is a professional surveillance products provider owing the ability of R&D, producing, marketing and service. Pearmain has a complete production line and endeavors itself to providing our customers with entire video surveillance system solutions.
Nowadays, Pearmain has developed itself into one of leading matrix manufacturers with 18 branches in China. We have 20 years of experience in designing and researching in video surveillance field. We specially focused on designing and producing high qualified HD matrix switcher. Our product compatibility enabled us to offer second development port or SDK for interconnection and communication from the 3rd party equipment or platform from almost 70 companies.
1. Does the product come with the cables or do they have to be ordered seperately?
All of the devices are assembled with cable and power adapter.
2. Are you a trade company or manufacturer?
We are a professional manufacturer and also a trade company.
3. What is your advantage in this field?
We have been designing & producing matrix switcher, keyboard controller and other surveillance system related products for almost 20 years in China. The compatibility & quality of our products is assured.
4. Can you design product with special functions for me?
We are professional OEM/ODM manufacturer, we are able to design the product according to your requirement as possible as we can.
5. If I am not clear about how to use the products, what should I do?
Each of our products has a manual, our professional after-sales team will support you in 24 hours if you have any question.
With years of export experience along with excellent quality, advanced services and competitive prices, PEARMAIN has won numerous customers' trust and support.
All packages are well protected in the cartons, so the products can be protected from damages.
Time of shipment ranges 5-7days according to different places.
For big orders, we will arrange Air Cargo or Ocean Freight with low delivery cost. Also, we can ship out with your specified shipment agent.
