Home > Products > Diesel Generators > OEM manufacture--power generating machines
OEM manufacture--power generating machines
- FUZHOU
- T/T
You May Like
Product Details
Place of Origin | Fujian, China | Brand Name | I-MAX | |
Model Number | IM20S | Output Type | AC Three Phase | |
Speed | 1500rpm / 1800rpm | Frequency | 50Hz or 60Hz | |
Rated Power | 20kva | Rated Voltage | 220v-440v | |
Rated Current | as per power |
Product Description
OEM manufacture--power generating machines
General Performance Feature
* Applied for continuous power generation
* High efficient, low noise power generation
* Heavy duty rubber anti-vibration mountings
* 12V / 24V starter batteries & connecting cables
* Industrial silencer, Residential silencer (optional)
* 40oC radiator as standard, 50oC is optional
* Key start panel control system as standard, digital auto-start panel is optional
* Full range protection function and alarm shutdown feature.
* ATS, AMF( Optional )
* Soundproof types( optional)
* Circuit breaker
* Oil Filter-Air filter
* Base fuel tank for 8 hour running at 100% load (optional)
* 1 year warantee
OEM manufacture--power generating machines
OEM manufacture--power generating machines
-- Specification
11KVA-47KVA / 50Hz | |||||||||
Model | Prime Power | Standby Power | Fuel ( L/h) | Engine | Open type Size & Weight | Weight | |||
KW | KVA | KW | KVA | Consumption | YangDong | L*W*H(mm) weight(kg) | |||
iMY-11 | 8 | 10 | 9 | 11 | 2.8 | YD385 | 1400*730*1080 | 500 | |
iMY-15 | 10 | 13 | 11 | 14 | 3.9 | YD480D | 1500*730*1080 | 520 | |
iMY-17 | 12 | 15 | 13 | 17 | 4.3 | YD4KD | 1500*730*1080 | 560 | |
iMY-19 | 14 | 18 | 15 | 19 | 4.6 | YND485D | 1660*730*1080 | 600 | |
iMY-22 | 16 | 20 | 18 | 22 | 5.5 | YSD490D | 1730*730*1150 | 680 | |
iMY-28 | 20 | 25 | 22 | 28 | 6.3 | Y490H | 1730*730*1150 | 720 | |
iMY-33 | 24 | 30 | 26 | 33 | 8.3 | Y4100D | 1730*730*1150 | 750 | |
iMY-39 | 28 | 35 | 31 | 39 | 8.5 | Y4102D | 1730*730*1150 | 850 | |
iMY-47 | 34 | 43 | 37 | 47 | 10.3 | Y4102ZD | 1900*750*1200 | 950 |
OEM manufacture--power generating machines
OEM manufacture--power generating machines
OEM manufacture--power generating machines
Power generating machine Warrantee: 1 year or 1200 hours. During the warranty period, our factory would be responsible for the problems caused by our production or raw material, we will offer technical support or sending spare parts for replacement if need except the spare parts which required periodic maintenance, and the damages caused by incorrect man-made operation will also fall outside the clause. After expiration, our company provides cost maintenance. Further terms could be negotiable!
ATTENTION: WHY CHOOSE FUZHOU 'I-MAX' GENERATORS?
If you are interested in the above products or would like to have more information, please visit our webiste or call us 0086-15860695366 (24 hrs online), we will get back to you as soon as possible!
