gasoline engine vertical shaft
US$ 68 - 78
/ Set
20 Sets(Min. Order)
- FUZHOU
- T/T
You May Like
Product Details
| Condition | New | Usage | Other, machine, auto tools, etc. | |
| Fuel | Gasoline | Stroke | 4 Stroke | |
| Cylinder | Single Cylinder | Cold Style | Other, Air-cooled | |
| Start | Electric Start | Place of Origin | Fujian, China | |
| Brand Name | I-MAX | Model Number | 5.5hp 6.5hp 7.0hp | |
| Dimension(L*W*H) | 470*430*480mm | Weight | 21 kgs | |
| Certification | CE ISO | Warranty | 12 months | |
| After-sales Service Provided | Overseas third-party support available |
Product Description
Specifications
gasoline engine vertical shaftOHV engine
5.5hp 6.5hp 7.0HP
CE,ISO
10 year manufacture
gasoline engine vertical shaft
Product Description
gasoline engine vertical shaft --Specification
| Model | iM168-1(160) | iM168-2(240) | iM170(E) | iM188(390)(E) | iM190(E) |
| Type | Vertical,air-cooled,4stroke, single-cylinder | ||||
| Bore x stroke(mm) | 68x45 | 68x45 | 70x54 | 88x64 | 90x66 |
| Displacement (ml) | 163 | 198 | 207 | 389 | 407 |
| Engine speed(rpm) | 3000/3600 | ||||
| Output | 5.5HP | 6.5HP | 7.0HP | 13HP | 15HP |
| Fuel consumption rate(g/kw-h) | < and =280/288 | ||||
| Fuel tank capacity(L) | 3.6 | 3.6 | 6 | 6 | 6 |
| Starting way | recoil starting/key starting | ||||
| Net weight(kg) | 15/17(E) | 15/17(E) | 15/17 | 31/33(E) | 31/33(E) |
| Dimension (mm) | 420x312x335 | 420x312x335 | 420x312x335 | 450x410x460 | 450x410x460 |
gasoline engine vertical shaft --5.5HP (IM168-1)
gasoline engine vertical shaft --IM168-2 (6.5HP)
gasoline engine vertical shaft --IM188 (13HP)
gasoline engine vertical shaft --IM188E (electric starter)(Optional)
Our Services
Warrantee: 12 months. During the warranted time, our company would be responsible for problems caused by quality of production or raw material, we send spare parts 2% which is problem free of charge, except the damageable spare parts of engines caused by incorrect man-made operation. After expiration, our company provides cost maintenance. Further terms could be negotiable!
If you are interested in the above products or would like to have more information, pls visit our webiste or call us 0086-15860695366 (24 hrs online), we will get back to you as soon as possible!
