Home > Products > Heat pipe solar collector > solar water collector system(WSP)
solar water collector system(WSP)
- Shanghai
- T/T
You May Like
Product Details
| Type | Evacuated Tube | Pressure | Pressurized | |
| Circulation Type | Indirect / Closed Loop (Active) | Heating System | Thermosyphon (Passive) | |
| Connection Type | Split | Installation | Freestanding | |
| Housing Material | Stainless Steel | Certification | CE, Other, CE, solar keymark | |
| Capacity | 300 | Place of Origin | Jiangsu, China | |
| Brand Name | wankang solar | Model Number | WSP |
Product Description
Heat pipe solar collector:
Manifold material and thickness | A, Black or silver aluminum alloy , thickness 2.0mm B, Stainless steel 304 2B, thickness 0.8mm |
Header pipe material and thickness | Diameter:32mm, thickness 1.0mm copper pipe |
Heat pipe material and thickness | Diameter:14mm, thickness 0.5mm copper pipe |
Insulation | Polyurethane foam 50mm or rock wool |
Test pressure and work pressure | Test pressure 9Bar, work pressure 6bar to 8bar |
Frame material and thickness | A, Aluminum alloy , thickness 2.0mm B, Stainless steel, thickness 1.2mm |
Collector mounting | Flat roof/slope roof |
Inlet and outlet | 1/2’’ OR 3/4’’ |
Hail resistance: | 25mm |
Coating of vacuum tube: | SS-C/CU |
