Product Details
| Place of Origin | Jiangsu, China | Brand Name | wankangsolar | |
| Model Number | WCD-58/1000-30tubes | Type | Pressurized | |
| Application | Water Heater | Pipe Material | Copper |
Product Description
Heat pipe solar collector For split pressurized solar system or Big project.
Features:
Material:
Manifold material and thickness | aluminum alloy-2.0mm/ Stainless steel 304 2B- 0.8mm |
Header pipe material and thickness | Diameter:32mm, thickness 1.0mm copper pipe |
Heat pipe material and thickness | Diameter:14mm, thickness 0.5mm copper pipe |
Insulation | Polyurethane foam 50mm or Rock wool |
Test pressure and work pressure | Test pressure 9Bar, work pressure 6bar to 8bar |
Frame material and thickness | Aluminum alloy-2.0mm/ Stainless steel-1.2mm |
Collector mounting | Flat roof/slope roof |
Inlet and outlet | 1/2’’ OR 3/4’’ |
Hail resistance: | 25mm |
Coating of vacuum tube: | QB-AL-SS/CU-47/1500/58/1800 |
