Slitting machine

Type	Slitting Rewinder		Computerized	Yes
Place of Origin	Zhejiang, China		Brand Name	RUIHAI
Model Number	WZFQ-A

Specifications

high speed slitting machine slit big roll to small roll
-high precision
-PLC control
-auto tension etc
-auto discharge roll

Performance and Characteristics

Slitting machine is used for slitting and rewinding various large rolling materials such as paper, (50g/~300g/ capacitance paper, bill paper), double-face adhesive tape, coated paper, aluminum foil, PVC, plastic material, etc. This machine use three motors synchronous for controlling, automatic taper tension, central surface reeling. Frequency converter timing for main motor, keeping speed up and stable operation. It has the functions of auto metering, automatic alarm, etc. Adopt A and B pneumatic shaft structure for rewinding, easy for loading and unloading. It adopts photoelectric automatic error correction adjustment system for unwinding, anomalistic materials will be easy slit. (or liquid press style subtense system) Equipped with automatic waste film blowing device. Automatic material loading by pneumatic, matched with inflatable shaft (3"or 6") or pneumatic non-shaft device



Machine Data of slitting machine



Model WZFQ- 1100A WZFQ- 1300A WZFQ- 1600A Max. Width of unwinding 1100mm 1300mm 1600mm Max. Diameter of unwinding Φ1400mm Φ1400mm Φ1400mm Min. Width of slitting 30mm 30mm 30mm Max. Diameter of rewinding Φ800mm Φ800mm Φ800mm Speed 10-160m/min 10-160m/min 10-160m/min Total power 12kw 12.8kw 16kw Suitable power supply 380V/50hz 380V/50hz 380V/50hz Weight (approx. ) 3000kg 3200kg 3800kg Overall dimension(LxWxH) 3000x2000x1600(mm) 3000x2400x1600(mm) 3000x2700x1600(mm)

Design and specifications are subject to change without notice.



Back viewing of the slitting machine:

Front viewing of the slitting machine:

Customer testing on our slitting machine before shipmment:



If need more pictures and detailed specification vedio of the slitting machine ,please be free to contact with us
