high efficiency coalescence oil filter

 coalescence Oil  filter

fiber is difficult of break away from

high precision , high filter efficiency

chemistry compatibility wide

filter element aperture compact

small filtration resistance

high flow

filter element accept dirt

long use life .etc.

ISO9001-2008

 coalescence  Oil  filter

Introduction: Oil suction filter element used to suck oil filter , filtering solid particle and colloidal material in the working medium. Effective control pollution degree in working medium . It install in the tank , and must install under the liquid level tank .The material of filter element is stainless steel or copper wire mesh , can repeated use clean.

Application fields : It is widely use pure water manufacture pretreatment , live drinking water , circulating cooling water , laboratory water , boiler water , oilfield flooding and food drink , chemical , make wine , pharmacy , electroplate , printing , paint , petroleum , electronic etc industry .

Advantages: It have many characteristics , for example : fiber is difficult of break away from , high precision , high filter efficiency , chemistry compatibility wide , filter element aperture compact , equality , small filtration resistance , high flow , filter element accept dirt , long use life .etc.

Material: end and bottom caps ,material : aluminum , stainless steel ;inner tube, material: galvanized sheet , stainless steel tube ; filter medium, material :stainless steel mesh and filter paper

DN (mm)

Nominal flow rate (L/min)

Filter precision (um)

Reset pressure loss(MPa)

Mating assembly model

LX-40

20

40

80
100
180

No more than 0.01

ISV20-40

LX-63

25

63

ISV25-63

LX-100

32

100

ISV32-100

LX-160

40

160

ISV40-160

LX-250

50

250

ISV50-250

LX-400

65

400

ISV65-400

LX-630

80

630

ISV80-630

LX-800

90

800

ISV90-800

LX-1000

100

1000

ISV100-1000

Model

DN(mm)

Nominal  flow rate(L/min)

Filter precision(um)

Reset pressure loss (MPa)

Mating assembly mode

TFX-25

15

25

80
100
180

No more than 0.01

TF-25 -L

TFX-40

20

40

TF-40 CL

TFX-63

25

63

TF-63 -L

TFX-100

32

100

TF-100 CL

TFX-160

40

160

TF-160 CL

TFX-250

50

250

TF-250 CL

TFX-400

65

400

TF-400 CL

TFX-630

90

630

TF-630 CL

TFX-800

90

800

TF-800 CL

TFX-1000

90

1000

TF-1000 CL

Model

DN(mm)

Nominal flow rate(L/min)

Filter precision(um)

Nominal pressure loss (MPa)

Mating assembly model

UX-25

15

25

80
100
180

No more than 0.007

NJU-25 CJ

UX-40

20

40

NJU-40 CJ

UX-63

25

63

NJU-63 CJ

UX-100

32

100

NJU-100 CJ

UX-160

40

160

NJU-160 CJ

UX-250

50

250

No more than 0.01

NJU-250 CJ

UX-400

65

400

NJU-400 CJ

UX-630

80

630

NJU-630 CJ

UX-800

90

800

NJU-800 -J

Model

DN(mm)

Nominal flow rate(L/min)

Reset pressure loss(MPa)

Filter precision(um)

Bypass-valve
Opening pressure(MPa)

Connection type

WU16J

12

16

No more than 0.01

80
100
180

Tuhular

WU-25J

15

25

0.02

WU-40J

20

40

WU-63J

25

63

WU-100J

32

100

WU-160J

40

160

WU-225GJ

50

225

WU-250FJ

50

250

Flange type

WU-400FJ

65

400

WU-630FJ

80

630

WU-800GJ

63

800

Tubular

WU-1000GJ

76

1000
