POE fiber media converter

Overview

FC520A-P is 100M POE HD Video Fiber Media Converter, which is specially designed for POE Network HD IP camera, POE wireless AP and other POE Network access control system. It supports IEEE802.3af 15.4W and IEEE802.3at 30W POE standards. It can auto discovery the power receiving devices which support IEEE802.3af/at standard and supply power to it. To the connected devices which not support PoE, it will auto stop supplying power. It supports long-distance stable HD Network video signals transmission through fiber cables.

Features

• PoE port supports to auto discovery the standard power receiving devices.
• Support IEEE802.3af 15.4W and IEEE802.3at 30W PoE standards
• Adopt special switch chipset design for HD Network video transmission;
• Support 3.2G bandwidth high-speed storing, forwarding and access;
• Support 100Base-FX fiber transmission standard, compatible with other Media Converters which supports 100Base-FX standard;
• Support full-duplex and half duplex transmission modes and capable of automatic negotiation;
• Support VLAN tag long packets transmission;
• Support flow control, QOS and STP
• Support max distance 120KM transmission;
• Used in remote side, supports to work with central side card type Media Converter FC520AC and Media Converter rack FTC-17 series, which supports dual power supply redundancy backup and hot swap;
• Support 1M built-in high-speed cache capacity and 2K built-in MAC address buffer space
• Support lightning protection for electrical ports, low consumption and low heat, support long-term stable work.


Technical Specifications

Ordering Information

 Certificates
