2 fiber ports 1 RJ45 port Node Media Converter

FOB Price

US$ 30 - 400 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	HiOSO
Model Number	FC650E

Product Description

FC650E Node Fiber Media Converters Series

Overview
HiOSO FC650E is a kind of 10/100Mbps adaptive fast Ethernet node type fiber media converter, with 1 10/100Mbps adaptive switch, which can implement mutual conversion between 10Base-T/100Base-TX twisted pair electrical signal and 100Base-FX optical signal. FC650F can extend the transmission distance of a network from 100m over copper wires to 120Km. This type of fiber converter supports two different types of network connection media types: 10/100Base-TX and 100Base-FX. With the application of the switching technology and the storing & forwarding technology, this kind of converter supports transmission in dual-fiber multi-mode,dual-fiber single-mode and single-fiber single-mode fibers.

Features

Adaptive 10Mbps and 100Mbps environments, for the convenience of network upgrade;
Efficient built-in switching core, to implement flow control and reduce broadcast packets;
Provide electrical interfaces based on VLAN switch setting, and supporting the connection of users from different units;
Support full-duplex and half duplex transmission modes and capable of automatic negotiation;
Support automatic crossing of twisted pair ports, for the convenience of system debugging and installation;
Support the transmission of extra-long packets (with the maximum length of 1552 bytes);
Support Quality of Service (QoS) and ensuring transmission of VoIP packets;
Support Spanning Tree Protocol (STP) to form a redundant network;
Low power consumption, low heat and capable of stable operation for a long period of time;
Support multiple types of fiber ports such as dual-fiber multi-mode,dual-fiber single-mode and single-fiber single-mode, expanding the requirements of users;

Application

10/100Mbps fast Ethernet long-distance transmission network

Technical Specifications

Parameter	Specifications
Access mode	10/100Mbps
Standard	IEEE802.3 10Base-T Ethernet, IEEE802.3u, 100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control, IEEE802.1q VLAN, IEEE802.1p QoS, IEEE802.1d Spanning Tree
Wavelength	850nm/1310nm/1550nm
Transmission distance	Dual-fiber multi-mode: 2Km; Dual-fiber single-mode: 25/40/60/80/100/120Km; Single-fiber single-mode: 25/40/60/80/100Km Category-5 twisted pair: 100m
Port	1 RJ45 connector, connected to STP/UTP category-5 twisted pair Two fiber port: Multi-mode - SC or ST (fiber size: 50,62.5/125μm) Single mode - SC/FC fiber port (fiber size: 9/125μm) Single-fiber single-mode - SC/FC fiber port (fiber size: 9/125μm)
Conversion mode	Medium conversion, storing and forwarding mode
MAC address table	I K
Buffer space	1Mbit
Flow control	Full duplex state: flow control; half duplex state: back pressure mode
Delay	9.6us
Bit error rate	<1/1000000000
MTBF	100,000 hours
LED	POWER (power), FX LINK/ACT (fiber connection/action) FDX (FX full duplex mode), FX100 (Fiber, with a transmission rate of 100M) TP1/2/3 LINK/ACT (1/2/3-port twisted pairs connection action) TP1/2/3100 (1/2/3-port twisted pairs, with a transmission rate of 100M)
Power	DC5V/1A (external)
Power consumption	3.5W
Operating temperature	-10~55℃
Operating humidity	5%~90%
Storage temperature	-40~70℃
Storage humidity	5%~90% (non-condensing)
Dimensions	26mm(Height)70mm(Width)98mm(Depth) (external power)

Order Information

Model	Rate (Mbps)	Mode	Working Wavelength (nm)	Transmission Distance (Km)	Fiber Interface	Power
FC650EM2-SC/ST	10/100	Dual-fiber multi-mode	1310	2	SC/ST	External DC5V/1A
FC650ES20/40/60 -SC/FC	10/100	Dual-fiber single-mode	1310	25/40/60	SC/FC	External DC5V/1A
FC650ES80/100/120-SC/FC	10/100	Dual-fiber single-mode	1550	80/100/120	SC/FC	External DC5V/1A
FC650FS-S20/40/60-SC	10/100	Single-fiber single-mode	1310/1550	25/40/60	SC	External DC5V/1A
FC650ES-S80/100-SC	10/100	Single-fiber single-mode	1310/1550	80/100	SC	External DC5V/1A
