Smart Home Security Control System FC300

Finseen New Cloud IP Technology Home Alarm

Smart Home Security Control System FC300

The Host

The IP Alarm’s scanner keeps watch in your home - even when you are not there.

The IP Alarm scanner is the alarm’s central component. It gathers data and starts the sirens in the event of fire and break-in.

The scanner sends data to IP Alarm’s protected servers online. Here is the data monitored and sent to your smartphone or tablet. For example by break-in, fire or smoke.
Unlike similar systems, IP Alarm is in constant contact with your home and you mobile devices. While you are away,IP Alarm’s keeps an eye on the activity in your home.

MOTION DETECTOR [PIR]

IP Alarm’s motion detector is what many call a PIR sensor (Passive Infrared) or PID sensor (Passive Infrared Detector).

In daily use, a motion sensor is one of the most important components in the surveillance of your home against break-ins. It is best placed in areas where you expect a thief to pass.

A little diode shows when the sensor is communicating with IP Alarm. All communication is done via the wireless technology, which the scanner and sensor utilize. You can see the sensor communicating when the light is on.

IP Alarm’s motion sensor is designed to work for up to 2 years on the same batteries. One of the tricks IP Alarm uses is that it detects less when you are home. This means that the sensor will typically only sweep things every 5 minutes. Should a thief pass the motion sensor it will of course react immediately.Therefore, if you 'play' with the sensor, you should know that there are a delay of up to 5minsbetween every reaction.

1. 1.      Persons who move across the motion sensor are seen best, so place the unit so that the thief passes by the sensor. See the illustration below.
2. 2.      Place the sensor ca 2-3m from the floor.



DOOR/WINDOW SENSOR

IP Alarm’s door/window sensor is an intelligent switch, which you attach to the doors and windows or other places in your home where you want control or an alarm in the event of a break-in.

The sensor is fitted with a discreet diode, which glows when the switch is communicating with the IP Alarm system.

Avoid drilling holes in your doors and windows. Both parts of the sensor should be appliedwith a little piece of special tape, which is included in the package.

  GASDETECTOR

It is vital that IP Alarm’s gas detector is correctly installed. According to which type of gas you wish to be able to detect, the unit must be installed thereafter. The various types of gas are best detected either at floor or ceiling level - depending on which type you wish to detect.

•    LNG (Natural gas)

LNG or liquefied natural gas is the liquid form of what we normally call natural gas. It belongs among the gas types, which are lighter than air and therefore seek upwards. If you want your gas detector to warn you of leakages of this type of gas, you must place it roughly 30cm from the ceiling. (See the illustration to your right).

•    LPG (Bottled gas)

LPG or liquefied petroleum gas can be bought bottled or delivered at petrol stations.
LPG is heavier than airand seeks downwards
in the eventof a leakage. The best place to

Installyour IP Alarm’s Gas detector to detect

this gastype would be ca 30cm from
the floor. (See the illustration to your right).

REMOTE CONTROL

IP Alarm’s remote has 4 buttons, which can be used separately.

Button 1:

- Disarming the burglary alarm or disconnecting in the event of an alarm.
- Disconnect the burglary alarm.
- Disconnect the home security mode.
- Stop an alarm where the sirens sound off.

Button 2:

Arm the system
Connect the burglary alarm.

Button 3:

Connecting the home security, secures the doors and windows in the system whilst your motion sensors stays inactive so you can stay in the house without the alarm sounding.

Button 4:

use this button, to activate the panic alarm. The system will send an alarm, for example by an assault. The sirens will not activate, but a message will be sent to those who you have included in your security service.

1. What's the difference between IP Cloud Alarm and GSM alarm system?
------ The GSM Burglar alarm system – can edit SMS and alarm information yourself by phone.

-------IP Cloud Alarm system—Do not need to charge your phone, just link to the Internet, then operate everything such as arm and disarm on your phone or tablet, and the IP Cloud Alarm will send you notification via your phone or email.

2. Why us?

• We are one of the two manufacturers who is the first one to produce this new product of the world
• We put millions of dollars on research and develop it with a foreign professional team together
• We have built 5 Cloud Server among 5 Countries of the world, 2 are in Europe, the other are in America, Singapore and China, more Cloud Servers can be built in the future.

3. How many wireless sensor can accept?
 ------- It can accept 99 wireless sensors including intelligent door sensor, PIR detector, smoke sensor, gas detector, etc.

4. Lightspot of our alarm system

1) Command for Arm delay,Alarm delay, Alarm zone with or without intellegent door sensor uploading open or close status function, active siren, close siren can be set through Internet.

2)Learn Remote Control and Detector ; Delete Remote Control and Detector.

3) Operate Alarm panel Away Arm, Home Arm, Disarm, Emergency Alarm through Internet.

4) Upload Status for Alarm panel: Away Arm, Home Arm, Disarm,Low voltage, Recovery of Low voltage, External power on, Cutting external power, Tamper-proof, Periodic upload(include Remote Control ID which operate Away Arm,Home Arm, Disarm).

5) Upload Low voltage of Detector, Alarm Zone, Tamper-Proof triggered.

6) Support setting alarm zone with intellegent door sensor function: triggerred by open or close door, and upload Status of Alarm zone

7) Alarm siren keeping time is 2minutes.

8) Can be set with 10pcs of Remote Control ID

9) Can be set with 99 wireless zone, and each zone can learn 1pc of accessories.
