7 Inch Sdi Screen Stabilizer Video Dslr Steadycam Vest Arm Lcd Wholesale Lcd Monitor
- xiamen
- T/T
You May Like
-
7 Inch Dslr Camera Cage Kit Lcd Handheld Stabilize Studio Video Broadcasting Monitor Audio Speakers
-
HDMI Input and Output 7 Inch Sdi Lcd Screen Resolution 1024X600 High Brightness Hdcvi Monitor
-
3.5" Small SDI Electronic Viewfinder Image Freeze and Flip HDSLR Cameras
-
Electronic Viewfinder 3.5 Inch 3G-SDI HDMI Input External Battery Plate for Cinema and Broadcasting
-
7 Inch 16:9 hd Field Screen Peaking Focus Assist Image Flip Car Lcd Monitor With Sun Shade
-
7 Inch Portable Small Tft Lcd Display Hdmi Input and Output Hd-sdi Cctv Test Monitor
Product Details
| Products Status | Stock | Application | Other, 7 hd sdi monitor | |
| Screen Size | Other, 7" | Response Time | 20ms | |
| Brightness | Other, 600cd/m | Interface Type | HDMI, Other, HDMI, SDI | |
| Contrast Ratio | 800:1 | Resolution | Other, 1024X600 | |
| Widescreen | Yes | Panel Type | IPS | |
| Pixel Pitch | 0.05(H) x 0.15 (V) mm | Brand Name | SEETEC | |
| Model Number | ST702HSD | Place of Origin | Fujian, China |
Product Description
7 inch sdi screen stabilizer video dslr steadycam vest arm lcd wholesale lcd monitor
SEETEC new release ST-702HSD 7-inch high-resolution monitor, with the main demands of premium, lightweight, clear, full functions. It is with 450cd/m2 brightness, 700: 1 high contrast ratio and 1024x600 resolution HD images, and it also provides a wide range of signal inputs,HDMI, SDI input and output, terminals to facilitate flexible use for the director. Complete Focus Assist, warning feature provides photographers to accurate diagnostic tool, to make wonderful film without defects. The setting knob and six shortcut keys make the monitor adjustment and settings more quickly.
| Description | 7" Pro-Broadcast HD Monitor | ||
| Model | ST-702HSD | ||
| Screen Size | 7'' | ||
| Panel Type | TFT LCD | IPS LCD | |
| Resolution | 1024x600 | ||
| Dot pitch | 0.05(H) x 0.15 (V) mm | ||
| Aspect ratio | 16:9 | ||
| Brightness | 450cd/m² | 600cd/m² | |
| Contrast | 700:1 | 800:1 | |
| Response time | 10ms | 20m | |
| Viewing Angle | 75°/75°(L/R) 70°/75°(U/D) | 85°/85°(L/R) 85°/85°(U/D) | |
| Backlight | LED | ||
| Video Format | PAL/NTSC | ||
| Inputs | HDMI,SDI | ||
| Outputs | HDMI,SDI | ||
| HDMI Support Mode | 480i / 576i / 480p/576p | ||
| 1080i (60/59.94/50) | |||
| 720p (60/59.94/50/30/29/25/24/23.98) | |||
| 1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF) | |||
| SDI Support Mode | ITU-R BT.656 | 576i | |
| SMPTE-125M | 480i | ||
| SMPTE-274M | 1080i(60/59.94/50) 1080p(30/29.97/25/24/24sF/23.98/23.98sF) | ||
| SMPTE-296M | 720p(60/59.94/50/30/29/25/24/23.98) | ||
| SMPTE-424M | 1080i(60/59.94/50) 1080p(60/59.94/50) | ||
| Power Consumption | ≤9W | ||
| Input Voltage | DC6V-24V | ||
| working Temperature | -20℃~50℃ | ||
| storage Temperature | -30℃~65℃ | ||
| Install Way | 1/4"-20 Thread Socket(All 4 Sides) | ||
| Unit Size | 194L × 148W ×28.5H(mm) | ||
| 194(L)x150(W)x62(H) mm With close sun shade | |||
| Unit Weight | ≈521 g(Contains F970battery plate) | ||
| ≈669g(Contains F970 battery plate and sun shade) | |||
1. Camera 5D II Mode
2. Peaking Focus Assist
3. Check Field (Mono/Red/Green/Blue)
4. Centre Marker
5. Screen Marker
6. Color Tempt. Adjustment
7. 4:3 &16:9 Image Adjustment
8.Pixel to Pixel
9.Image Flip
10. Knob Menu Selection, Volume Control
11. Feature Options Shortcuts Panel Operation, Simple and Efficient
Innovational OSD Operation
ST-702HSD double function knobs are SEETEC's exclusive technology feature, which will bring you more convenient and rapid operation feeling.
Inputs and Outputs
ST-702HSD is with SDI and HDMI inputs and outputs. Since the monitor is all digital, it shows the purest and cleanest signal directly on the LCD panel. To remove the legacy analog inputs and circuits makes your image as clean as possible
