SMB Plug Male Connector Crimp RG316 RG174 LMR100
Negotiable
/ Piece
100 Pieces(Min. Order)
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DM, DM | |
| Model Number | SMB plug male connector crimp RG316 RG174 LMR100 | Type | Other, SMB, SMB plug male connector crimp RG316 RG174 LMR100 | |
| Application | Other, RF, RF | Gender | Other, Male, male |
Product Description
SMB plug male connector crimp RG316 RG174 LMR100
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥1000MΩ | |||
| Characteristic impedance | 50Ω/70Ω | Dielectric Withstanding voltage | 750V(r ms) | |||
| Frequency range | 0~4GHz(50Ω) | Voltage rating | 250V(r ms) | |||
| 0~2GHz(75Ω) | ||||||
| Contact resistance | Center conductor | ≤6mΩ | VSWR | ≤1.30 | ||
| Outer conductor | ≤1mΩ | Durability | ≥500 Cycles | |||
| Material And Plating | ||||||
| Body | Brass , gold plated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Beryllium copper , gold plated | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
