SMA Female to Female Flange Connector
Negotiable
/ Piece
100 Pieces(Min. Order)
- shenzhen
- Credit Card
You May Like
-
BNC Female Jack Center Solder PCB Mount RF Coxial Cable Connector Converter for Mobile Signal Booster Repeater Antennas
-
RF Connector N Male Right Angle Crimp Type for RG174
-
MMCX Female Bulkhead Coaxial Connector for RG174 RG316 Cable
-
RF Connector MCX Female Right Angle Crimp RG174 RG316
-
MMCX Female Coaxial Connector for Pcb
-
MMCX Male Right Angle Connector
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DM, DM | |
| Type | Other, SMA, SMA | Application | Other, RF, RF | |
| Gender | Other, Male, male |
Product Description
Series SMA are very popular thread coupling miniature coaxial connectors.Which have the excellent performances of high reliability,high mechanical strength,high durability,and optimum electrical properties, are widely used to connect RF coaxial cables for mobile communication equipments and electronic communication instruments
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1000V(r ms) | |||
| Frequency range | With flexible cable | 0~12.4GHz | Contact resistance | Center conductor | ≤3mΩ | |
| With semi-rigid/flexible cable | 0~18GHz | Outer conductor | ≤2mΩ | |||
| VSWR | With flexible cable | ≤1.15+0.02F | Durability | 500 Cycles | ||
| With semi-rigid/flexible cable | ≤1.05+0.02F | |||||
| Material And Plating | ||||||
| Body | Brass , gold plated or stainless steel passivated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicon rubber | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
