WR Series Thermocouple With Knit for Refinery,High Presssure Polyethylene and Chemical Industry
- Chongqing
- Credit Card
You May Like
Product Details
| Place of Origin | Chongqing, China | Brand Name | Haichen Thermocouple | |
| Model Number | WR | Usage | Industrial | |
| Theory | Temperature Sensor |
Product Description
Thermocouple with Knit for Refinery,High Presssure
Polyethylene and Chemical Industry
Pt13-Rh thermocouple (r type thermocouple)is precious metal thermocouple.Wire diameter is 0.5mm,Tolerance is -0.015mm,the chemical constituent of BP is Pt-Rh alloys,contains Rh13%,Pt is 87%,BN is pure platinum.The r type thermocouple uses the highest temperature is 1300°C in a long-term,the highest temperature is 1300°C in a short-term .
In thermocouple series,r type thermocouple has high accuracy,best stability,wide measuring area,long service life,high temperature limit,etc.It applies to oxidation and inert atmosphere.
The shortcoming of r type thermocouple is thermoelectric potential rate is small,low sensitivity,in high temperature,the mechanical strength decline,it is sensitive to pollution.The precious metals is expensive,so investment is larger in one time.
Model & Specification
| Model NO. | Graduation | Temperarure Range(°c) | Marerial of Protection Tube | Thermal Response Time | OD | Length Depth | |
WRQ-130 WRQ2-130 | R | 0-1600 | high alumina | <150s | Φ16 | 300*150 350*200 400*250 450*300 550*400 650*500 900*750 1150*1000 1650*1500 2150*2000 | |
WRQ-131 WRQ2-131 | R | 0-1600 | <150s |
