Home > Products > CAST RESIN TRANSFORMER > 500 KVA CAST RESIN TRANSFORMER TRANSFORMER
500 KVA CAST RESIN TRANSFORMER TRANSFORMER
- Mumbai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Gujarat, India | Brand Name | PEC | |
| Model Number | 1500 KVA | Usage | Power | |
| Phase | Three | Coil Structure | Other, epoxy | |
| Coil Number | Other, 3 |
Product Description
Specifications
500 KVA CAST RESIN TRANSFORMER TRANSFORMER1.High quality
2.Reasonable price
3.Delivery on time
4.Quality Assurance
- POWER is an ISO 9001:2000, DUN BRADSTREET (862376458), IEC, FGI, DIC, EEPC & NSIC registered company. Having five manufacturing plants in all over India. We are engaged in the manufacture of Industrial Transformers up to 10 MVA (Epoxy Cast Resin Construction, Dry Type, Oil Cooled) low and medium voltage, Industrial Automatic Voltage Stabilizer ranging up to 7000 KVA capacity (U.K. based Brentford type), Variable voltage supply (0 – 33000 Volts), Special Purpose Transformers (step up / step down, auto transformers, Ultra Isolation Transformers), Rectifier equipments from 0-1500 Volts and up to 25,000 Amps. for Industrial applications.
Rated power [kVA] | Rated voltage [kV] | No-load losses [W] | Load Losses [W] | Total Weight [kg] | Dimensions | ||
Lenth [mm] | Width [mm] | Height [mm] | |||||
630 | 12 | 1150 | 6400 | 2070 | 1470 | 835 | 1505 |
| 24 | 1500 | 6000 | 2100 | 1600 | 850 | 1400 |
| 36 | 2200 | 7000 | 2900 | 2070 | 940 | 1650 |
800 | 12 | 1450 | 7800 | 2430 | 1590 | 855 | 1640 |
| 24 | 1600 | 7500 | 2550 | 1650 | 855 | 1620 |
| 36 | 2600 | 8200 | 3300 | 2140 | 950 | 1850 |
1000 | 12 | 1650 | 8900 | 2850 | 1620 | 990 | 1795 |
| 24 | 1850 | 8700 | 3060 | 1680 | 990 | 1815 |
| 36 | 3000 | 9500 | 3900 | 2200 | 1050 | 1900 |
1250 | 12 | 1850 | 10500 | 3370 | 1790 | 990 | 1705 |
| 24 | 2100 | 10500 | 3490 | 1850 | 990 | 1675 |
| 36 | 3500 | 11000 | 4500 | 2300 | 1060 | 2000 |
1600 | 12 | 2100 | 11400 | 4170 | 1880 | 1005 | 2065 |
| 24 | 3100 | 11800 | 3640 | 1880 | 995 | 2035 |
| 36 | 4300 | 12700 | 5600 | 2500 | 1100 | 2400 |
2000 | 12 | 2650 | 14500 | 5140 | 1990 | 1280 | 2205 |
| 24 | 3000 | 14900 | 4920 | 2040 | 1280 | 2180 |
| 36 | 5100 | 15400 | 6300 | 2500 | 1280 | 2400 |
2500 | 12 | 3000 | 18400 | 6230 | 2170 | 1280 | 2205 |
| 24 | 3600 | 18000 | 6220 | 2220 | 1280 | 2180 |
|
|
- Power Engineers Company is Manufacturer, Exporter & Supplier of a wide range of electrical equipment. The company has soared to enviable heights in the domain, under his able leadership.
Contact Us
- Power Engineers Company
- Contact nameATUL KHOSLA Chat Now
- Phone91-9714-777713
- Address967/2/2, GIDC, MAKARPURA,
