(Manufactory) High quality low price auto Mini gps antenna

FOB Price

USD $2 - $3 / Piece

20 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	JIASHANJINCHANG
Model Number	JCA057

Mini gps antenna
Center Frequency 1575.42 MHz
Band Width 5 MHz
LNA Gain 29 dB
Noise Figure 1.5 dB

Mini gps antenna

1 Electrical Characteristics

1.1 Dielectric Antenna

Form 1

No.	Item	Specifications	Post Environmental Tolerance
1	Center Frequency	1575.42 MHz	±3 MHz
2	Band Width	±5 MHz	±1 MHz
3	V.S.W.R(in BW)	1.5:1	—
4	Gain(Zenith)	3 dB	±0.5 dB
5	Polarization	RHCP	—
6	Impedance	50	—

1.2 LNA/Filter

Form 2

No.	Item	Specifications	Post Environmental Tolerance
1	LNA Gain	28±2 dB	±2.5 dB
2	Noise Figure	1.2 dB	—
3	Filter Out Band Attenuation	12dB Min f0+50MHz 16dB Min f0-50MHz	±1.0 dB
4	DC Voltage	2.2~5 V
5	DC Current	5~15 mA

1.3 Mechanical

Form 3
