HOT GPS ACTIVE EXTERNAL ANTENNA
US$ 3.00 - 3.00
/ Piece
100 Pieces(Min. Order)
- SHANGHAI
You May Like
-
(Manufactory) High Quality External Gps Car Antenna
-
(Manufactory) Free Sample High Gain 1575.42 MHz Car Passive Gps Antenna
-
(Manufactory) High Gain 1575.42 MHz Car Passive Gps Antenna
-
(Manufactory) High Quality 42dbi Waterproof White GPS Antenna
-
(Manufactory) High Quality Low Price 1575.42mhz Gps Car Antenna
-
(Manufactory)High Quality Low Price GPS Circular Antenna
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JINCHANG | |
| Model Number | JCA001 |
Product Description
Product Description
- Type: Gps Antenna
- Use: Automotive
- Place of Origin: Zhejiang, China (Mainland)
- Brand Name: JINCHANG
- Model Number: JCA001
- Center Frequency: 1575.42 MHz±3 MHz
- Gain: 3 dB±0.5 dB
- type: GPS active antenna
1 Electrical Characteristics
1.1 Dielectric Antenna
Form 1
No. | Item | Specifications | Post Environmental Tolerance |
1 | Center Frequency(MHz) | 1575.42 MHz | ±3 MHz |
2 | Band Width(MHz) | ±5 MHz | ±1 MHz |
3 | V.S.W.R(in BW) | 1.5:1 | — |
4 | Gain(Zenith) | 3 dB | ±0.5 dB |
5 | Polarization | RHCP | — |
6 | Impedance | 50 Ω | — |
1.2 LNA/Filter
Form 2
No. | Item | Specifications | Post Environmental Tolerance |
1 | LNA Gain | 28±2 dB | ±2.5 dB |
2 | Noise Figure | 1.5 dB | — |
3 | Filter Out Band Attenuation | 12dB Min f0+50MHz 16dB Min f0-50MHz | ±1.0 dB |
4 | DC Voltage | 2.2~5 V | |
5 | DC Current | 5~15 mA | |
1.3 Mechanical
Form 3
No. | Item | Specification |
1 | Cable | RG174 3m/5m or others |
2 | Connector | SMA/SMB/MCX or others |
3 | Plastic Housing | Black |
4 | Mounting | Magnet/Adhesive |
Packaging & Shipping
| Packaging Details: | 49.5*22*27CM |
|---|---|
| Delivery Detail: | 5 WORK DAYS |
