Heating Thermal Oil Boiler/heater

Technical parameters:

Type:BGY25-380/300

Explosion-proof degree:ExdⅡCT4,protection degree:IP55

Working power:300KW

Operating temperature:310℃

Heated medium: Heat conduction oil

Operating pressure:0.6MPa

Description:

The electric heater is mainly consist of pressure vessel, heating elements, control cabinet and skid, which form the high efficiency and energy saving equipment.

The heating elements are arranged evenly inside the electric heater, the heated medium goes through the pressure vessel which directly heated by the heating elements to reach the required temperature of the process.

Set over-temperature protection thermocouple inside the electric heater,once the medium over-temperature, the heater will disconnect immediately to protect the heating elements.Also set thermocouple at the outlet of the heated medium to measure the outlet temperature, the automatic constant temperature control cabinet pressure regulating systemaccurately control the output power of the electric heater to ensure the outlet temperature error is less than ± 1 ℃.

Features:

It is a new type of science and technology innovation product and has won a number of invention patents.This heater is mainly used to heat the heated medium directly which has advantages like high thermal efficiency, quick heat transfer, occupies less space,safe and reliable.

Application:

The product is widely used in Petrochemical enterprises such as Oil Refinery,Offshore Platform etc..Indirect heating electric heater made by our company is widely used in large petrochemical enterprises such as Daqing Oilfield,Shenyang Blower Factory and CNOOC etc.Due to energy saving, small footprint and high thermal efficiency, win the users’ consistent high praise, establish long-term relationship of cooperation.

Products On Site:

Zhenjiang YuTai Explosion-proof Electric Heater History:

Established in 1983, Zhenjiang YuTai Explosion-proof Electric Heater Co., Ltd focus on manufacturing the exposion-proof electric equipments and elements.

Relying on our excellent quality, We have got a lot of certificates, such as ATEX,CE,CCS and so on.

We have nearly 40 patents which honored us the High-tech enterprise of Jiangsu province.

Factory and Office:

When you send me inquiry,please mark:

1. Type of heater
2. Wattage and voltage
3. Diameter & length of the heater,flange size
4. Drawing or sample required for special configuration

Any question,please feel free to contact with me any time!!!
