Industrial electrical heating gasifier heater with good quality device

Main technical parameters:

1.Production Standard:GB3836.1~3-2010;JB/T2379-93

2.Medium:Ethylene

3.Tube side:Working condition 1: 500x1.1kg/hr; Working condition 2: 2250x1.1kg/hr

4.Heat transfer medium(tube side): Methanol

5.Shell working temperature:65℃

6.Shell design temperature: -105℃/155℃

7.Shell working pressure: 105.635KPa(A)

8.Shell design pressure: 1500KPa(G)

9.Contain type(shell ): II type

10.Tube side inlet and outlet temperature of the work: -102.01℃(inlet)/40℃(outlet)

11.Tube side design temperature: -104℃/65℃

12.Tube working pressure(max): 6.2MPa(G)

13.Tube design pressure: 7.1MPa(G)

14.Contain type(tube side ): II type

15. heat exchange area:45m2

16.Power supply: AC380V 50HZ 3Φ

17.Total power: 375KW+25KW(spare);Power of each heating tube:25KW

18.Protection level of the connection box:IP55

19.Explosion-proof level of the connection box:ExdIIBT4

Description:

EthyleneIndirect electric heating carburetor is a efficient and energy-saving equipment which set the heating and heat exchange as a whole. It is made by horizontal structure that mainly composed of three parts which like carburetor shell,heat exchanger and electric heating tube.

Ethylene Indirect electric heating carburetor heat methanolin the shell by 16 electric heating tube. Put ethylene into the exchange tube, the 16 electric heating tube heat methanol under the carburetor shell to make it gasification, all the heat goes to the top of shell, when

methanolgas contact ethylene in the exchange tube, hot and cold meet,methanol gas turns to condensed water and goes to the bottom of the shell, then heat it by the exchange tube again and so on, Neither consumed methanol, ethylene in the exchange tube can be heated to the desired temperature.

Features:

It is a new type of science and technology innovation product and has won a number of invention patents. This product is mainly used for heating flammable, combustible and high pressure medium indirectly which has advantages like high thermal efficient, quick heat transfer, occupies less space and safe and reliable.

Products On Site:

Zhenjiang YuTai Explosion-proof Electric Heater History:

Established in 1983, Zhenjiang YuTai Explosion-proof Electric Heater Co., Ltd focus on manufacturing the exposion-proof electric equipments and elements.

Relying on our excellent quality, We have got a lot of certificates, such as ATEX,CE,CCS and so on.

We have nearly 40 patents which honored us the High-tech enterprise of Jiangsu province.
