industrial electric air heater for natural gas

Technical parameters:

Type:BGY25-380/50

Explosion-proof degree:ExdⅡCT4,protection degree:IP55

Working power:50KW

Operating temperature:450℃

Heated medium:natural gas

Operating pressure:15MPa

Description

The electric heater is mainly consist of pressure vessel and heating elements,which form the high efficiency and energy saving equipment.

The heating elements are arranged evenly inside the electric heater, the heated medium goes through the pressure vessel which directly heated by the heating elements to reach the required temperature of the process.

Set over-temperature protection thermocouple inside the electric heater,once the medium over-temperature, the heater will disconnect immediately to protect the heating elements.Also set thermocouple at the outlet of the heated medium to measure the outlet temperature, the automatic constant temperature control cabinet pressure regulating systemaccuratelycontrol the output power of the electric heater to ensure the outlet temperature error is less than ± 1 ℃.

Features

It is a new type of science and technology innovation product and has won a number of invention patents.This heater is mainly used to heat the heated medium directly which has advantages like high thermal efficiency, quick heat transfer, occupies less space,safe and reliable.

Application

The product is widely used in Petrochemical enterprisessuch as Oil Refinery,Offshore Platform etc..Indirect heating electric heater made by our company is widely used in large petrochemical enterprises such as Daqing Oilfield,Shenyang Blower Factory and CNOOC etc.Due to energy saving, small footprint and high thermal efficiency, win the users’ consistent high praise, establish long-term relationship of cooperation.

Serial automatic constant temperature SCR voltage regulator cabinet:

Our factory produces Model YTFB automatic temperature controlled SCR voltage-regulating cabinet (referring to the voltage regulator thereinafter) which can be widely used in power plant, petroleum, oil exploitation, chemical industry, aerospace, offshore platform etc.It can heat various kinds of gases and liquids such as water coal gas, hydrogen, nitrogen, ate, crude oil, heating conducting oil, chloromethane etc.,and can make voltage regulation and constant temperature.

As the trigger control circuit (referring to the trigger thereinafter) adopting special integrated circuit and interlligence,it can obviously rise up stability and reliability of the voltage regulator.It has a serial of advantages of small volume, light weight,high efficient,long service of life,flexible control, smooth regulating, good symmetric three phases and easy maintenance,especially the starting (operation) of the large power electric heater has no shock and fluctuation agains the power network in the factory area,and it has manual and automatic control function to measure and control temperature,digital setting,automatic lowering voltage to reach constant temperature finally therefore it is really the most ideal equipment in heating temperature control or voltage-lowered power supply devices.

Company Introduction:

Zhenjiang YuTai Explosion-proof Electric Heater Co.,Ltd is a high-tech real manufacturer, with 30 years rich experience in production electric heating fields, also have many years successful experience in design and production which are accumulated from large-scale engineering projects. Our company covers area 20000m2. We have 150 employees, including 47 middle and high ranking technicians. We have passed the National Safety Standard Factory Acceptance inspection.
