Home > Products > Metal Keypad > Customized Compact
Customized Compact
US$ 1 - 300
/ Set
1 Set(Min. Order)
- Shen Zhen and HK
- T/T Credit Card T/T
You May Like
-
IP65 Industrial Slim Metal Usb Numeric 4x4 Keypad for Mini Device
-
Flexible Programmble Dot Matric Industrial Free Custom Layout Keypad
-
16 Keys Industrial Dot Matrix Metal Keypad
-
Flexible Industrial Matrix Metal Programmable Keypad
-
16 Keys IP 65 Vandal Proof Long Stroke Metal Numeric Keypad
-
Movable Desktop Metal Numeric Metallic Keypad for Smart Card Reader
Product Details
| Place of Origin | Guangdong, China | Brand Name | Key-Tek | |
| Model Number | K-TEK-A120PP | Application | Other, Bank kiosks, ATM, CDMs etc | |
| Keypad Button Material | Metal |
Product Description
16 keys IP65 vandal-proof stainless steel encryption PINPAD with encryption module supporting DES/TDES is suitable for ATM/CDM, all kinds of bank terminals etc, with carbon-on-gold key switch technology with long stroke 2.0mm, with top panel mounting solution
APPLICATION
- This encryption METAL PINPAD is mainly targeted for use for unsupervised or semi-supervised positions of varied bank access applications, Bank kiosks, ATM, CDMs etc.
MAIN FEATURE
- Stainless steel fascia and key-tops guard willful destruction, against corrosion, shock, dust, falling raining, splashing, hose-directed water and vandal resistant, operation under hostile environments.
- Internet friendly key layout, key-tops are sunk laser-etched in legends and characters via using high quality ink for easy readability, long life to prevent lettering rub-off. Or protrusive engraving available.
- The PINPAD in 4 x 4 matrix with Enter, Cancel, Correction, etc. compliance with ISO standard.
- 16 bytes keys (16 master keys x 4 working keys), it can be self destructive with back-up battery to achieve this function.
- The PINPAD can be used as a keypad for numeric entry.
- The ATM can instruct PINPAD to exit key entry/supervisory mode.
COMMUNICATION PARAMETER
- Standard RS232 serial interface.
- Communication velocity: 19200, 9600, 4800, 2400, 1200bps.
- Data format: N, 8, 1.
- 16 actuators: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, correct, enter, cancel, backup key 3 defined for ABC.
- Data encryption and decryption (DES/TDES), MAC Algorithm.
- Encryption rate: < 1 second.
MECHANICAL DATA
- Actuation Force: 0.6N +/-0.1N (pressure point) for key 14.0mm x 14.0mm, 1.2N +/-0.1N (pressure point)
- Key Stroke: 2.0mm.
- Front panel: brushed stainless steel.
- Actuator/keys materials: stainless steel.
- Mechanical Key lifespan: 10 Mio actuations.
- Lettering: laser engraving or raised letter.
- Dimensions: 120.0mm x 98.0mm (front plate).
- GW: 1.0Kg.
ELECTRICAL DATA
- Switching Material: Carbon-on-Gold.
- Power Supply Voltage:+5V DC.
- Power consumption:Under 1W for operating condition, 200mA for non-operating condition.
- EMC: EN55022(B).
- Communication Interface: RS232 or USB available.
- Enter PIN: 10 numerical keys and 6 function keys.
ENVIRONMENTAL ADAPTABILITY
- Operating temperature: -20°C to +60°C.
- Storage temperature:-30 °C to +70°C.
- Operating RH: 3090%.
- Atmospheric pressure: 60106Kpa.
- Keypad is watertight while being mounted correctly on ATM.
RELIABILITY
- RoHS Compliant, CE and FCC
- Protection Level: IP65(front panel)
- Vandal resistant IK10
- Sensitive data can be well saved while sudden power off.
- Sensitive data and program can be erased when being tampered.
- Key Lifespan > 10 million actuations.
- MTBF >20000H.
- MTTR <30min.
