Home > Products > Industrial Pointing Devices > 2016 New Rear Panel Mounting IP65 Industrial Metal Ruggedized Touchpad
2016 New Rear Panel Mounting IP65 Industrial Metal Ruggedized Touchpad
US$ 89 - 199
/ Piece
1 Piece(Min. Order)
- SHEN ZHEN AND HK
- T/T Credit Card T/T
You May Like
-
38mm Waterproof Vandal Proof Stainless Steel Trackball Pointing Mouse
-
IP68 Washable Optical Metal Trackball
-
38mm Integrated Trackball With Three Buttons
-
38mm Stainless Steel Waterproof Indsutrial Metal Trackball
-
38mm Optical Stainless Steel Waterproof Industrial Metal Trackball
-
38mm Vandal Proof Waterproof Stainless Steel Trackball
Product Details
| Products Status | Stock | Brand Name | key-tek | |
| Model Number | K-TEK-B83TP | Place of Origin | Guangdong, China |
Product Description
Product Description
Model NO:K-TEK-B83TP
Dimension:83.0mm x 110.0mm (front panel)
Description:IP65 dynamic Sealed and Ruggedized Touchpad with scroll function optional for fast and accurate cursor position, with stainless steel housing protects the electronics controller module, IP65 dynamic rated sealed stainless steel mouse buttons under touchpad, with rear panel mounting.
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | ||
| Mechanical | Front Plate | Quality brushed stainless steel | |
| Touchpad thickness | 1.3 mm PCB thickness inclusive of mylar layer | ||
| Validated touch width | 46.50mm (max) | ||
| Validated touch length | 62.50mm (max) | ||
| Mounting Rack | Aluminum alloy | ||
| Back Metal Cover | Rear side integrated electronics protected by a metal cover | ||
| Touchpad lifespan | > 10 Mio times | ||
| Dimensions | Touchpad: 65.0mm x 49.0mm; Front Mounting Panel: 83.0mm x 110.0mm (front panel), Rear Mounting Panel: 107.0mm x 134.0mm | ||
| Interface | PS2 and USB both available | ||
| Electrical | Power supply | 5V DC+ 10%, | |
| Work current | 4.0 mA (normal) | ||
| X/Y position sensing resolution: | 1000 points/inch (40 points/mm) | ||
| X/Y position reporting: | Relative | ||
| Tracking speed: | Maximum 1,016 m/sec | ||
| Protection level: | IP65 (front panel) | ||
| Static Release: | 15 KV (front panel) | ||
| EMC Standard: | EN55022(B) | ||
| Environmental | Operating temperature: | -20°C to +60°C | |
| Storage temperature: | - 40°C to + 70°C | ||
| Operating RH: | 10%-95% | ||
| Atmospheric pressure: | 60-106Kpa | ||
| Reliability | MTBF | >20000h | |
| MTTR | < 30min | ||
| Touchpad Lifespan | >10 million actuations | ||
| OS | OS is under DOS/Windows95/98/NT/ME/2000/XP/2003/Vista, Linux, Unix, Mac OS9 / OSX | ||
| Packing Details | Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton. | ||
