Gas Atomization Metal Powder Maker Equipment
- shenzhen/guangzhou
 - T/T

You May Like
Product Details
| Condition | New | Type | Other, metal powder gas atomized equipment | |
| Usage | Other, atomize metal into powder | Place of Origin | Hunan, China | |
| Brand Name | ZZHHGY | Voltage | 380V | |
| Power(W) | 100KW | Weight | 500KG | |
| Certification | CE, ISO | Warranty | 1-5years | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Gas Atomization Metal Powder Maker Equipment
Gas atomization equipment’s applications and theory:
It’s a device which satisfies the formation of spherical metal powder in certain circumstance.Working principles:metal melting and alloy under the protection of the gas, meltal liquid flows out through the insulation crucible and diversion mouth by high pressure airflow, when it flows through the nozzle,metal liquid atomized into large quantity of small drops, then it solidifies into spherical and semi-spherical particals, through screening and separation,it can be made into metal powder.Features:
1. Gas atomization way to make metal and alloy powder which most of common equipment can not do.
2. Produce spherical and semi-spherical type powder
3. For the solidification conques the segregation, some special alloy powder can be produced.
4. Adopt suitable process, the powder can reach the certain requirement.
1. Capacity power: 25 kg 50kg 100kg 200kg
2. Medium Frequency Power: 100kw 160kw 250kw
3. Intermediate Frequency:2500hz
4. Vacuum pressure rise rate: 0.05pa/min
5. Holding furnace power: 10-25kw
6. Holding funace temperature: 900-1200℃ (Resistance heating)
7. Melting furnace temperature: 1800℃
8. Cooling tower pressure: 0.3mpa
9. Cooling water flow: 8-12T/h


Zhuzhou Han He Industrial Equipment CO.,LTD. located in Zhuzhou, a emerging industrial city in central south of China. It is a High-tech enterprise that research, produce and sales the high- middle-frequency power, the complete set induction heating equipment and the non-sign electric heating equipment. The company has abundant technical force and strong research and development ability. It is equipped with a team made up of experts and doctors, and establishes the close cooperation with many scientific research institution and induction heating equipment companies in Europe.
Currently, we mainly produce middle frequency induction melting furnace, middle frequency induction heating furnace, complete sets of middle-high-frequency quenching equipment, middle frequency bender equipment, middle frequency carbide furnace, vacuum induction melting furnace, vacuum induction sintering furnace, hydrogen sintering furnace, polysilicon directional solidification furnace, bright annealing furnace pipe, steel pipe straight seam welding annealing equipment, compound pot bottom high frequency brazing machine, Conduction of heat heating machine before rub pressure welding for the compound metal pot bottom, round-link chain induction heating machine and so on. We can also accept the design and construction of the non-sign induction heating equipment and other electric heating equipment.
1. How about the warranty?
All our products have one year quality warranty, during the warranty time, the spare parts replacement is free. And we provide life long time technical support and other assistance.
2. How to install your machine?
We have paper installation instructions and videos, we will teach till you learn it.
3. How about the payment terms and delivery time?
Payment terms for small machines: 100% T/T in advance.
The big machines and big amount: 50% deposit 50% before shipment (we will shoot total delivering process for customer's confirmation) and the related papers. You can pay by T/T or other ways.
The small machine delivery time is within 10 days, the bigger one takes about 15-20days, and we will delivery goods on time.
4. Is your goods has ISO9001 ?
Yes, all our goods has ISO. All machines are high quality goods.
5. What is your nature of your company: Trade Company or factory?
We are manufacturer with a big factory, warmly welcome to visit our factory and contact us
