Home > Products > Graphite and carbon furnace > Intermediate Frequency Silicon Alloy Carbide Furnace
Intermediate Frequency Silicon Alloy Carbide Furnace
- Guangzhou/ Shenzhen
- T/T Credit Card
You May Like
Product Details
| Condition | New | Type | Induction Furnace | |
| Usage | Other, carbide furnace | Place of Origin | Hunan, China | |
| Brand Name | ZZHHGY | Model Number | ZVF630 | |
| Power(W) | 160KW 200KW 250KW | Dimension(L*W*H) | 3.0*1.8*2.5m | |
| Weight | 200kg | Certification | ISO9001 | |
| Warranty | 1year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Intermediate frequency silicon alloy carbide furnace
1. Usage
Hard alloy, powder alloy industry, production of various granular tungsten carbide, titanium carbide, vanadium carbide, metal powder, metal powder sintered alloy and composite, such as tungsten and molybdenum products.
2. Features
Function
1) 2400℃ super-high temperature stainless steel furnace body with water cooling.
2) Meet heating technology of thin, middle, coarse particles and compound material carbonization. It is also used in alloy material sintering supervising system for the working and device with trouble self-diagnosis.
3) Adopt number display intelligent control temperature system, Finish temperature measure and control with auto high precise, It can raise temperature according to the setting raising temperature curve, and storage 20 groups, 20 different heating curve for each group. Or It can be controlled by manual work.
4) Adopt pure water cycle processing system: Number-supervising system for the rate of flow, middle frequency contact device with high function, auto-control system with PLC, and automatic detection discharge of water with CPU
5) The carbonized quality has the distinct improvement with this new furnace, compares with the traditional carbide furnace, it has the superiority with the complete response, the even granularity, the high chemical combination carbon amount, low dissociation carbon amount and has the characteristics with the high output, the good work condition, life long.
6) The control push-button is few, function is entire, the operation of control panel is simple, you can install the touch-screen to realize the man-machine surface system
Rated power:160KW 200KW 250KW
Rated frequency:4000Hz
Highest application temperature:1600℃ 2400℃
High temperature area volume:450×900mm
Working Atomosphere: Hydrogen, nitrogen, argon, inert gas
Temperature even value:<±12℃
Temperature measurement scope:200-2200℃, 800-2400℃
Temperature measurement: Infrared optical measurement
Control temperature precise:±1℃
Limit raising temperature speed :400℃/min
Customized designs are available.
Zhuzhou Han He Industrial Equipment CO.,LTD. located in Zhuzhou, a emerging industrial city in central south of China. It is a High-tech enterprise that research, produce and sales the high- middle-frequency power, the complete set induction heating equipment and the non-sign electric heating equipment. The company has abundant technical force and strong research and development ability. It is equipped with a team made up of experts and doctors, and establishes the close cooperation with many scientific research institution and induction heating equipment companies in Europe.
Currently, we mainly produce middle frequency induction melting furnace, middle frequency induction heating furnace, complete sets of middle-high-frequency quenching equipment, middle frequency bender equipment, middle frequency carbide furnace, vacuum induction melting furnace, vacuum induction sintering furnace, hydrogen sintering furnace, polysilicon directional solidification furnace, bright annealing furnace pipe, steel pipe straight seam welding annealing equipment, compound pot bottom high frequency brazing machine, Conduction of heat heating machine before rub pressure welding for the compound metal pot bottom, round-link chain induction heating machine and so on. We can also accept the design and construction of the non-sign induction heating equipment and other electric heating equipment.
1. How about the warranty?
All our products have one year quality warranty, during the warranty time, the spare parts replacement is free. And we provide life long time technical support and other assistance.
2. How to install your machine?
We have paper installation instructions and videos, we will teach till you learn it.
3. How about the payment terms and delivery time?
Payment terms for small machines: 100% T/T in advance.
The big machines and big amount: 50% deposit 50% before shipment (we will shoot total delivering process for customer's confirmation) and the related papers. You can pay by T/T or other ways.
The small machine delivery time is within 10 days, the bigger one takes about 15-20days, and we will delivery goods on time.
4. Is your goods has ISO9001 ?
Yes, all our goods has ISO. All machines are high quality goods.
5. What is your nature of your company: Trade Company or factory?
We are manufacturer with a big factory, warmly welcome to visit our factory and contact us
