Motorized Linear Moving Stages (Round guide type)
- XINGANG
- T/T Credit Card PayPal
You May Like
-
mini motorized rotation stage(diameter 60mm)
-
rotary stage, motorized rotary stage, manual rotary stage
-
Heavy Loading Motorized Rotation Stage (diameter 200mm with 90mm through hole)
-
Precision Motorized Rotation Stages
-
High Quality Heavy Loading Motorized Rotary Stage (diameter 300mm)
-
Black- Anodized Aluminum Alloy motorized rotary stage,OD300MM
Product Details
| Place of Origin | Hebei, China | Brand Name | MEMORY | |
| Model Number | 04DP100 |
Product Description
Motorized Linear Moving Stages (Round guide type)
1. Specification:
Model Number | 04DP100 | 04DP150 | 04DP200 | 04DP300 | 04DP400 | 04DP500 | 04DP600 | ||||||
Travel Range | 100mm | 150mm | 200mm | 300mm | 400mm | 500mm | 600mm | ||||||
Bearing | High Precise Ball Screw with 4mm leading | High Precise Ball Screw with 5mm leading | |||||||||||
Travel Guide | Round rail | ||||||||||||
Stepper Motor | 1.8° 2-phase STP-57D3016 stepper motor (servo optional) | ||||||||||||
Material- Finish | Aluminum Alloy Black-Anodized | ||||||||||||
Max Load Capacity | 30kg horizontal/ 15kg vertical | ||||||||||||
Weight | 4.0kg | 5.5kg | 5.9kg | 6.3kg | 7.0kg | 12.0kg | 15.0kg | ||||||
Resolution | 20μm /pulse, non-ms driver 1μm /pulse, 20ms driver | 20μm /pulse, non-ms driver 1.25μm /pulse, 20ms driver | |||||||||||
Max Speed | 40mm/sec | 50mm/sec | |||||||||||
Repeatability | 8μm | ||||||||||||
Absolute Accuracy | 10μm | ||||||||||||
Straightness | 15μm | 30μm | 60μm | ||||||||||
Degree of Parallelization | 20μm | 25μm | 30μm | ||||||||||
Pitching | 80” | 80” | 80” | ||||||||||
Yawing | 60” | 60” | 60” | ||||||||||
Backlash | 8um | ||||||||||||
Optional Accessories | Brake Function, Grating Scales, Servo Motor and Dust Cover | ||||||||||||
2. Features:
1) Regular type set with small 1.8°2-phase stepper motor
2) High precise ball screw provides high-performance and high-accuracy
3) Round guide for long travel but low-loading use
4) Special design for couple with other stage easily
5) The basic type can set with grating scales, servo motor
6) RS232 interface for connecting motion controller easily
3. Specification For The Model:
(Model Number) | 04DP50 | 04DP100 | 04DP150 | 04DP200 | 04DP300 | 04DP400 | 04DP500 |
L | 252 | 302 | 352 | 402 | 502 | 602 | 702 |
4. Drawing:
5. Products:
1.High quality 5 layer postal boxes which can bear 25 kg pressure
2.Professional packaging technology Let transport do not have trouble back at home.Special factors such as heavy
weight,complicated modelling, some products need special packaging to use carton splicing or use foam packing box, etc.
Please rest assured the packaging , we will take with product safety as the prerequisite and adopt suitable packing.
3.According client's requirements.
Buying guide:
To get an inquiry,you only need to send us
1.Drawing(Dimensions ,material,need surface treatment or not,
any special requirements)
2.Quantity
3.If didn't have the drawing,customer can give a rough dimensions
and the model picture to get a estimated price,if feel the price is ok,
can send the sample for us to get more accurate quote .
Feel Free to contact me for any questions.
