TCRT5000 Tracing sensor Obstacle avoidance module Infrared reflectance sensor
- hk
- Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | china | |
| Model Number | TCRT5000 |
Product Description
Specifications
TCRT5000 Tracing sensor Obstacle avoidance module Infrared reflectance sensor
application
1 meter pulse sampling
2 fax paper shredder paper detection
3 obstacle detection
4 black and white line detection
SPECIFICATION
1 the TCRT5000 infrared reflection sensor
2 testing reflection from 1 mm to 25 mm
3 clean comparator output signal waveform good driving ability more than 15 ma
More than four with adjustable precision potentiometer sensitivity adjustment
5 working voltage of 3.3 V to 5 V
6 output in the form of digital switch output (0 and 1)
7 a fixed bolt hole is convenient to install
8 small board PCB size 3.2 CM * 1.4 CM
9 USES the LM393 wide voltage comparator
Function introduce
TCRT5000 infrared emitting diode constantly launch infrared sensor when the infrared reflected back were not reflected or but strength is not enough when the infrared receiving tube has been in the off state at this time the output of the module for high level just diode has been put out state is detected object appeared in the detection range is infrared light is reflected back and infrared receiving tube when the saturation intensity is wide enough module at this time is the opening for the diode lit up low level instructions
Connection mode
The positive 3-5 v 1 VCC power connection
GND connect power cathode
