1KVAonline UPS
- shenzhen
You May Like
Product Details
Place of Origin | Guangdong, China | Brand Name | Hedwin | |
Model Number | C1K | Phase | Single Phase | |
Protection | Overcurrent | Weight | 14.5kg | |
Output Voltage | 220v | Type | On-line | |
Application | Computer |
Product Description
Specifications
800w, LCD panel, 115-300V input, 220V output, RS232 and SNMP slot included, 12V,7Ah*3 battery
C1-3K(S)
Outstanding Features
LCD panel
Cold start
DSP, IGBT,PFC Technology
0.8 output power factor
Automatic recharge even UPS is off
Intelligent Battery Management (IBM)
Beeping Alarm on Battery, Battery Low and Overload
Automatic Adjustment to 50Hz/60Hz Power Supply System
Strong Expansion Function, Webpower, AS400, RS485, SNMP card could be installed.
Application
Data center, Point-of-sale, Router, Hub and other network device, Precision instrument.
Technical Spec
Model | C1K | C1KS | C2K | C2KS | C3K | C3KS | ||||||
Rated power | 1000VA/800W | 2000VA/1600W | 3000VA/2400W | |||||||||
AC Input | Input system | Single phase & earth ground | ||||||||||
Range voltage | 210/220/230Vac | |||||||||||
Frequency | 50/60Hz | |||||||||||
Voltage range | 115~300VAC±5@half load; 176-296VAC±5@full load | |||||||||||
Frequency range | 45~55Hz±0.5Hz or 55~65Hz±0.5Hz auto sense | |||||||||||
Power factor | 0.99 | |||||||||||
Voltage range of bypass | 65VAC×(1±5%)~280VAC×(1±5%) | |||||||||||
Battery Input | Type | Lead-Acid maintenance-free | ||||||||||
Voltage range of battery | 36VDC (24V/48Voptional) | 72VDC(48V/96VOptional) | 96VDC (48V/72VOptional) | |||||||||
Bat Number | 3 (2/4 optional) | 6 (4/8 optional) | 8 (4/6 optional) | |||||||||
Inside batteries | 12V7AH | - | 12V7AH | - | 12V7AH | - | ||||||
Backup Time | Standard ups: Half loaded≥10minutes,Full loaded ≥5minutesLong backup ups: depend on the external batteries | |||||||||||
Charging current | 1A | 7A | 1A | 7A | 1A | 7A | ||||||
Battery charged time | Standard ups: 5 hrs to 90% battery capacity | |||||||||||
Long backups ups; depend on the capacity of external batteries | ||||||||||||
AC Output | Output system | Single phase & earth ground | ||||||||||
Output voltage | 210/220/230Vac±2% | |||||||||||
Output frequency | 50±5Hz(line normal, according to line) 50Hz±1%(line abnormal) | |||||||||||
Dynamic voltage transient range | <5% | |||||||||||
Dynamic transient restore | < 60ms | |||||||||||
Waveform | True sine wave | |||||||||||
Power factor | 0.8 | |||||||||||
Overload capability | 105~125%≥ 30s,126~150%≥200ms The recovery point is 90% | |||||||||||
Current peak coefficient | 3:1 | |||||||||||
Transfer time | 0ms (AC to DC) | |||||||||||
< 4ms(AC to Bypass) | ||||||||||||
Efficiency | 85% | 88% | ||||||||||
THD | <2% full load(linear load) | |||||||||||
Panel display | LCD and LED | I/P Voltage, I/P& Frequency,Battery voltage,UPS status, load, temperature,O/P Voltage,Frequency, B/P Voltage,Frequency | ||||||||||
Interface | Communications | RS232,Intelligent Slot (Web power card, or As400 Card Optional),Dry contacts optional | ||||||||||
Power Outlets | No. and types | 2 SOCKETS | 4 SOCKETS | 3 SOCKETS and 1 terminal | ||||||||
Function | Cold start | DC Power on | ||||||||||
Automatic Charge | Automatic Charge when UPS is off |
