Tray freeze dryer| Lyophilizer|Lyopjilization|Freeze drying machine|Vacuum Dryer|Vacuum freeze |

FOB Price

USD $40,000 - $60,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Freeze Drying Equipment
Place of Origin	Shanghai, China	Brand Name	LYOMAC
Model Number	lyopro-0.4	Voltage	380-460V
Power(W)	5	Dimension(LWH)	12009502200
Weight	500kg	Certification	CE
Warranty	12 months	After-sales Service Provided	Engineers available to service machinery overseas

Description

Features

Shelf temperature range from -40 °C~80 °C, and regulatable for processoptimization or development before industrial production.
Vacuum can be regulatable, by clean air injet, or chamber isolation valve operation, this can accelerate drying process.
Vial rubber cap closing under vacuum by hydraulic stoppering mechanism.
Fully stainless steel fabrication, easily clean.
Both vial and trays can be loaded.
All critical system backup design to avoid cycle collapsed during process.

Optional System/Part

CIP(cleaning in place) and SIP(Sterilization in place) system.
Computer based SCADA system, all data can be recorded by table or curve type, easily print out for preservation.
Adjustable shelf space mechanism.
Vial stoppering system.

Specification List

Type	LYOPRO-0.2	LYOPRO-0.4	LYOPRO-0.6
Shelf area (m2)	0.24	0.40	0.60
*Shelf size (LWT)(mm)*	40030013	45030013	50030013
Useable Shelf No.	2	3	4
Vial loading quantity Φ16 Φ22	980 500	1660 875	2460 1300
Inter. Shelf distance (mm) *	100	100	100
Ice capacity (KG)	4	8	10
Shelf ultimate cooling temperature(°C)(air/water/cascade cooling system)	-45/-50 /-60	-45/-50 /-60	-45/-50 /-60
Condenser ultimate cooling temperature(°C) (air/water/cascade cooling system)	-60/-70 /-80	-60/-70 /-80	-60/-70 /-80
Ultimate vacuum(Pa)	≤1.0	≤1.0	≤1.0
*Installation dimension(LWH)(mm)*	1009501400	200012002400	210012002600
Weight(Kg)	600	1000	1500
Power(KW)	4	5	7

Shanghai Lyomac Technology Co., Ltd.: Contact nameRobert Wang
Chat Now; Phone0086-21-24208788; Address103, Floor 1, Bldg. 6, No. 588, Caonong Road
