Product Details
| Place of Origin | Hunan, China | Brand Name | SINOBOOM | |
| Model Number | GTJZ0808 |
Product Description
Mobile hydraulic scissor lift is mainly used for flat indoor or outdoor. The body is pleasing to eye; the product is compact in structure and flexible to operate. The main engine is designed as dual-driven dual steering with self-travelling and turning functions. It features imported hydraulic components, explosion-proof pipe unit and emergency descending unit; hydraulically driven travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground; optimized product control mode and procedure with the premise of safety, bringing much more humanized operation.
Technical parameters
Models | GTJZ0808 | |
Measurements | Metric | US |
Dimensions | ||
Platform height max. | 8.1 m | 27 ft |
Working height max. | 10.1 m | 33 ft |
Platform exetended | 0.9 m | 3 ft |
Length-stowed | 2.39 m | 7 ft 8 in |
Width-stowed | 0.81 m | 2 ft 7 in |
Height-folding guardrails | 2.35 m | 7 ft 7 in |
Height-rails folded | 1.96 m | 6 ft 4 in |
Height-fixed rails | 2.35 m | 7 ft 7 in |
Ground clearance | 0.1 m | 4 in |
Wheelbase | 1.85 m | 6 ft |
Platform size (L*W*H) | 2.25 m *0.81 m *1.1 m | 7 ft 5 in *2 ft 7 in *3 ft 6 in |
Productivity | ||
Max. platform occupancy | 2 | 2 |
Lift capacity | 250 kg | 551 lbs |
Lift capacity-ectension deck | 120 kg | 265 lbs |
Drive speed-stowed | 0~3.2 km/h | 0~2 mph |
Drive speed-raised | 0~0.8 km/h | 0~0.5 mph |
Gradeability | 25% | 25% |
Turning radius-inside | 0 m | 0 ft |
Turning radius-outside | 2.1 m | 6 ft 9 in |
Raise/Lower speed | 33/ 37 s | 33/ 37 s |
Controls | Proportional | Proportional |
Drives | Dual front wheel | Dual front wheel |
Brakes | Dual rear wheel | Dual rear wheel |
Tire size(solid non-marking) | 380 mm * 125 mm | 15 in * 5 in |
Power | ||
Power source | 24V DC (4*6V, 225Ah batteries) | 24V DC (4*6V, 225Ah batteries) |
Hydraulic system capacity | 18 L | 4.76 gal |
Power | 3 KW | 3 KW |
Weight | ||
Indoor | 1920 kg | 4233 lbs |
Standards Compliance | CE/ISO/ADR/ARAMCO | CE/ISO/ADR/ARAMCO |
