China Manufacturer Sales 2015 All Types of Scissor Lifts
- Chinese main ports
- T/T
You May Like
-
China Manufacturer Supplier Hydraulic Aluminum Work Platform,building Construction Maintenace
-
Diesel Engine Scissor Lift , 8m-10m Diesel Engine Lift Table
-
China Manufacturer Wholesale Aerial Scissors Lift,movable Small Platform Scissor Lift,hydraulic Electric Mini Scissor Lift
-
Self-Propelled Outdoor Hydraulic Vertical Lift Platform for Sale
-
Hot Sale Hydraulic Mobile Scissor Hydraulic Lift
-
Cleaning Building Equipment Working at 10m Height Platform,aerial Work Platform,self-propelled Hydraulic Platform
Product Details
| Place of Origin | Hunan, China | Brand Name | SINOBOOM | |
| Model Number | GTJZ | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Hydraulic | Power | 3KW | |
| Rated Loading Capacity | 230kg-380kg | Min. Lifting Height | 0.76m | |
| Max. Lifting Height | 6.6-13.9m | Table Size | - | |
| Overall Dimensions | - | Weight | 1210-3902kg | |
| Certification | CE/ISO/ADR/ARAMCO | Warranty | one year | |
| After-sales Service Provided | Overseas service center available |
Product Description
Scissor Lift is composed of diesel scissor lift and motor-driven scissor lift in terms of power type, and hydraulic scissor lift and motor-driven lift in terms of travel methods.
Technical parameters
Models | GTJZ0408S | GTJZ0608S | GTJZ0608 | GTJZ0808 | GTJZ1012 | GTJZ1212 |
Dimensions | ||||||
Platform height max. | 4.6m | 5.8m | 6.3m | 81m | 10m | 11.9m |
Working height max. | 6.6m | 7.8m | 8.3m | 10.1m | 12m | 13.9m |
Horizontal extended | 0.9m | 0.9m | 0.9m | 0.9m | 0.9m | 0.9m |
Length-stowed | 1.775m | 1.775m | 2.39m | 2.39m | 2.39m | 2.39m |
Width-stowed | 0.76m | 0.76m | 0.81m | 0.81m | 1.15m | 1.15m |
Height-stowed | 2.08m | 2.06m | 2.22m | 2.35m | 2.48m | 2.6m |
Ground clearance | 0.07m | 0.07m | 0.1m | 0.1m | 0.1m | 0.1m |
Wheelbase | 1.315m | 1.315m | 1.85m | 1.85m | 1.85m | 1.85m |
Platform size (L*W*H) | 1.64*0.76* 1.1m | 1.64*0.76* 1.1m | 2.25*0.81* 1.1m | 2.25*0.81* 1.1m | 2.25*1.15* 1.1m | 2.25*1.15* 1.1m |
Productivity | ||||||
Max. platform occupancy | 2 | 2 | 2 | 2 | 2(indoor) 1(outdoor) | 2(indoor) 1(outdoor) |
Lift capacity | 280kg | 230kg | 380kg | 250kg | 320kg | 320kg |
Lift capacity-extension deck | 120kg | 120kg | 120kg | 120kg | 120kg | 120kg |
Drive speed-stowed | 0~4km/h | 0~4km/h | 0~3.2km/h | 0~3.2km/h | 0~3.2km/h | 0~3.2km/h |
Drivie speed-raised | 0~0.8km/h | 0~0.8km/h | 0~0.8km/h | 0~0.8km/h | 0~0.8km/h | 0~0.8km/h |
Gradeability | 30%
| 30% | 30% | 25% | 25% | 25% |
Turning radius-inside | 0m | 0m | 0m | 0m | 0m | 0m |
Turning radius-outside | 1.48m | 1.48m | 2.1m | 2.1m | 2.35m | 2.35m |
Raise/ Lower speed | 18/30s | 18/25m | 27/33 s | 33/307 | 55/42s | 65/47s |
Tire size(solid non-marking) | 305*115mm | 305*115mm | 380*125mm | 380*125mm | 380*125mm | 380*125mm |
Power | ||||||
Power source | 24V DC (4*6V, 225Ah batteries) | 24V DC (4*6V, 225Ah batteries) | 24V DC (4*6V, 225Ah batteries) | 24V DC (4*6V, 225Ah battery) | 24V DC (4*6V, 225Ah battery) | 24V DC (4*6V, 225Ah battery) |
Hydraulic system capacity | 18L | 18L | 18L | 18L | 18L | 22L |
Power | 3KW | 3KW | 3KW | 3KW | 3KW | 3KW |
Weight | ||||||
Indoor | 1210kg | 1328kg | 3902kg | 1920kg | 2380kg | 2615kg |
Indoor & outdoor general | - | - | - | - | 2570kg | 2900kg |
Standards compliant | CE/ISO/ADR /ARAMCO | CE/ISO/ADR /ARAMCO | CE/ISO/ADR /ARAMCO | CE/ISO/ADR /ARAMCO | CE/ISO/ADR /ARAMCO | CE/ISO/ADR /ARAMCO |
