Cleaning Building Equipment Working at 10m Height Platform,aerial Work Platform,self-propelled Hydraulic Platform

Self-propelled hydraulic scissor lift is mainly used in flat indoor or outdoor. It features imported hydraulic components, explosion-proof pipe unit and emergency descending unit; hydraulically driven travelling function; low in noises and free of air pollution; durable, chip-free, skid-proof and traceless tires without scratching the ground.

Technical parameters

Models	GTJZ0818D
Dimensions
Platform height max.	25.9 ft (7.9 m)
Working height max.	32 ft (9.9 m)
Platform extended	4.92 ft (1.5 m)
Overall Length(stowed,with outrigger/without)	12ft/10.8ft(3.77m/3.29m)
Overall width(stowed)	5.77 ft (1.76 m)
Overall height (stowed,guardrail folded/unfolded)	6 ft (1.9 m)/8.2ft(2.50m)
Wheelbase	7.48 ft (2.28 m)
Ground Clearance	0.72 ft (0.22 m)
Platform size (L*W*H)	9 ft*5.24ft*3.6ft   (2.8 m*1.6 m*1.1 m)
Productivity
Max. platform occupancy	4(indoor),  4(outdoor)
Lift capacity	1499 lbs (680 kg)
Lift capacity - extension outreach	308 lbs (140 kg)
Driving speed - stowed	0~5.6 km/h
Driving speed - raised	0~0.48 km/h
Gradeability	40%
Turning radius - inside	6.9 ft (2.11 m)
Turning radius - outside	15 ft (4.6 m)
Rising / Falling speed (without loading)	29s~39s / 26s~36s
Controls	Proportional
Drive&steer model	4WD*2WS
Hydraulic system pressure	24Mpa
Tire Size/type	26*12-16.5/solid foam
Power
Control voltage	12VDC
Hydraulic system tank vol.	85 L
Fuel tank vol.	48 L
Weight
Overall weight (with outrigger/without)	8631 lbs (3915 kg) /  7617 lbs (3455 kg)
StandardsCompliance	CE/ISO/ADR/ARAMCO
