Home > Products > 50 Pin Connector > Male Plug 50 Pin Telecom Connector 25 Pair PCB Mount Right Angle
Male Plug 50 Pin Telecom Connector 25 Pair PCB Mount Right Angle
US$ 1 - 2
/ Piece
1000 Pieces(Min. Order)
- Guangzhou / Shenzhen
- T/T Credit Card
You May Like
-
57 Series 50 Pin Connector 25 Pairs PCB Mount DIP Right Angle 2.16mm Pitch Header Connector Male Plug Type
-
Right Angle Mounting Amphenol Female Socket 50 Centronic Connector 25 Pairs Solder DIP Receptacle Type
-
Soler DIP Type 57LE Amphenol Right Angle PCB Mount Header Connector 50 Way Female Receptacle
-
50 Pin Receptacle Right Angle Solder DIP 57LE Amphenol PCB Mount Connector 25 Pairs Female
-
57CN 25 Pairs Right Angle PCB Mounting Connector 50 Pin Female Receptacle Type
-
57 Series 50P Communication Female Connector Right Angle PCB Mounting 25 Pairs
Product Details
| Brand Name | FUYCONN | Model Number | FUY57015-50P | |
| Place of Origin | Guangdong, China |
Product Description
Specifications
Item No.: FUY57015-50P1,ROHS compliant, UL-approved
2,High quality, Competitive price
3,Quick delivery time
4,Free sample
Specifications
Product features
Product Type: Connector
Product Line:CENTRONIC
Connector Style: Female
Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
PCB Mount Style: Right Angle
Orientation:Standard
Mechanical Attachment
Panel Attachment Style:Rear to Rivet
Insulator Material:Thermoplastic
Terminal Related Features
Certerline :2.16mm(0.85 in)
Number of Position: 14,24,36,50,64 pin
PCB Mount Retention Type: Right Angle
Contact Plating: Gold (A:5u" ,B10u",C:15u",D:30u")
Contact Material: Copper Alloy
Housing Features
Connector Style: Receptacle
Housing Material: Steel
UL Flammability Rating: UL 94V-O
Special Function
A:90°C DIP pan holes type
B:Pan holes,riveting
C:“L”Fork Board Lock
Finish
Electrical Specifications:
Current Rating: 5Amp
Voltage rating: DC 1000v per minute
Insulator Resistance: 1000Mn MIN.(at 500V DC)
Operation Temperature: -55°C to +105°C
Application
| 1, VDSL Telecom Equipment | |
| 2, Computer Peripherals | |
| 3, Communication Equipment | |
| 4, PCB Board | |
| 5, Cable to Panel | |
| 6, Cable to cable | |
| 7,Computer terminal | |
| 8,Telemetering | |
| 9,Test Equipment | |
| 10, Printer |
Technology Parameters
