Home > Products > 24 Pin Connector > 2.16mm Pitch Receptacle Right Angle PCB Mount 24 Pin Header Connector Female
2.16mm Pitch Receptacle Right Angle PCB Mount 24 Pin Header Connector Female
US$ 0.5 - 2
/ Piece
1000 Pieces(Min. Order)
- Shenzhen / Guangzhou
- T/T Credit Card
You May Like
-
DDK DIPT Type 2.16mm Centerline Female Centronic Connector 24 Pin PCB Mount
-
24Pin DDK DIP PCB Mounting Right Angle Male Plug Centronic Connector 2.16mm Pitch Champ Type
-
2.16mm Pitch Champ PCB Straight Solder DIP Termination Female Header Connector 24 Way
-
PCB Mount Solder DDK DIP Termination 24 Way Female Socket Connector 2.16mm Pitch Champ
-
DDK 24pos Female PCB Straight Mount Solder DIP Termination Champ Connector 2.16mm
-
Female Receptacle Type 2.16mm DDK DIP 24 Pin Socket Connector PCB Mounting Header With Spring Latches
Product Details
| Brand Name | FUYCONN | Model Number | FUY57001-24P | |
| Place of Origin | China |
Product Description
Specifications
Product features
Product Type: Connector
Product Line:CENTRONIC
Connector Style: Female
Shell: Stainless steel,Zinc plated,Tin ploted or Nickel plated steel
PCB Mount Style: Right Angle
Orientation:Standard
Mechanical Attachment
Panel Attachment Style:Rear to Rivet
Insulator Material:Thermoplastic
Terminal Related Features
Certerline :2.16mm(0.85 in)
Number of Position: 14,24,36,50pin
PCB Mount Retention Type: Right Angle
Contact Plating: Gold (A:5u" ,B10u",C:15u",D:30u")
Contact Material: Copper Alloy
Housing Features
Connector Style: Receptacle
Housing Material: Steel
UL Flammability Rating: UL 94V-O
Special Function
A:90°C DIP pan holes type
B:Pan holes,riveting
C:2.6mm “Z”Fork Board Lock
Finish
Electrical Specifications:
Current Rating: 5Amp
Voltage rating: DC 1000v per minute
Insulator Resistance: 1000Mn MIN.(at 500V DC)
Operation Temperature: -55°C to +105°C
Application
| 1, VDSL Teleccom Equipment | |
| 2, Computer Peripherals | |
| 3, Communication Equipment | |
| 4, PCB Board | |
| 5, Cable to Panel | |
| 6, Cable to cable | |
| 7,Computer terminal | |
| 8,Telemetering | |
| 9,Test Equipment | |
| 10, Printer |
Technology Parameters
