Insulating Glass Processing Machine Full Automatic CNC Insulating Glass Flat-press Process Line
- Qingdao
- T/T
You May Like
-
Insulating Glass Processing Machines Rubber Appllication Table
-
Heated Roller Press Used for Insulating Glass Processing
-
Aluminum Windows&doors Processing Machine Digital Display Double Mitre Saw
-
Insulating Glass Production Machine Glass Edge Grinding Machine
-
Insulating Glass Production Line (Roller Press)
-
Insulating Glass Processing Machine Vertical Insulating Glass Production Line (Plate Press)
Product Details
| Condition | New | Machine Type | Insulating Glass Production Line | |
| Place of Origin | China | Brand Name | JINANYUEFENG | |
| Model Number | GPL-XY2000B | Dimension(L*W*H) | 19000*2350*3030mm | |
| Certification | CE |
Product Description
Specifications
1.Full automatic PLC control.2.Full distance five step frequency control .
3.Elegant appearance and never rust.
Introduction:
1. Three pairs brushes available for low-E glass.
2.PLC control two touch screen system, realize temperature, speed, output and machine
trouble prompting, realize whole line under automatic control.
3. Realize glass pressing automatically outside or inside the press machine, produce
insulating glass with two or three pieces original glass. It could produce insulating glass
come from glasses that is same size or different size.
4. Full distance five step frequency control speed changing, the waiting section of line save
time for whole process and improve working efficiency.
5. Action board can open, easy to examine and repair.
6. When glass is pressed, the front and back part of flat pressing machine will up the glass
with lever-type arm and hand system, (mechanical position + mobile sucking system) all
this will ensure no malposition.
7. Inside part of Wash machine, dry machine and the air dryer are both stainless steel
production. It is elegant appearance and never rust.
Technical Parameter:
Model | GPL-XY2000B |
Input voltage | 380V 50Hz |
Input power | 24.5Kw |
Max. glass size | 2000×2500~2600mm |
Min. glass size | 280×400mm |
Glass thickness | 3~18mm |
Working speed | 8~48m/min |
Overall dimension | 19000×2350×3030mm |
